BLK BOX 50-0141 Owner's Manual & Quick Start Manual

Reverse hyperextension

OWNERS MANUAL & QUICK START GUIDE

NOTE : PLEASE READ ALL THE INSTRUCTIONS

CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.

BLK BOX

REVERSE HYPEREXTENSION

50-0141

PRODUCT SPECIFICATION

PRODUCT WEIGHT

MAX USER WEIGHT

MAX USER

MAX TRAINING WEIGHT

DIMENSIONS

1268mmx912mmx1228mm

#MADEINBELFAST

50kg

125kg

350kg

Table of Contents

Need help?

Do you have a question about the 50-0141 and is the answer not in the manual?

Page 1 BLK BOX REVERSE HYPEREXTENSION 50-0141 PRODUCT SPECIFICATION PRODUCT WEIGHT 50kg MAX USER WEIGHT 125kg OWNERS MANUAL & QUICK START GUIDE MAX USER MAX TRAINING WEIGHT 350kg NOTE : PLEASE READ ALL THE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING THIS PRODUCT. 1268mmx912mmx1228mm DIMENSIONS...
Page 2 WARNING SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS EN- SURE BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER RE- DUCE RISK OF INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
Page 3 ASSEMBLY BOLT 1QTY REVERSE HYPER SIDE (21-0833) AND 1QTY REVERSE HYPER SIDE FRAME SIDE PLATE (21-0639) TO 1QTY REVERSE HYPER TOP (21-1001) WITH BOLT ASSEMBLIES AS SHOWN BELOW. REPEAT ON OTHER SIDE. ENSURE THE ORIENTATION OF SIDES ARE CORRECT. BOLT ASSEMBLY FOR EACH HOLE: 10.0006 10.0019 x2...
Page 4 TIGHTEN ALL BOLT ASSEMBLIES TO 30NM AND ENSURE ALL ATTACHMENTS ARE PLUMB. 1:1 SCALE FASTENERS M10x80 BOLT 10-0006 M10 FLAT WASHER NYLOCK NUT 10-0019 10-0024 FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT: www.blkboxfitness.com/pages/terms-conditions GET IN TOUCH: TEL: 028 9045 4123 EMAIL: info@blkboxfitness.com DISCOVER MORE AT: www.blkboxfitness.com...
