Section 7 - Specifications
XL5100V
Wheelbase ............................................................................................14.3 ft (4,4 m)
Ground Clearance ...............................................................................10 in (254 mm)
Transport Length (without bucket) .........................................................25.6 ft (7,8 m)
Transport Height (without bucket) (6x4) ................................................11.2 ft (3,4 m)
Transport Height (without bucket) (6x6) ................................................11.5 ft (3,5 m)
Transport Width .......................................................................................8.6 ft (2,6 m)
Note: Refer to detailed specification sheet for additional machine dimension
information. Specification sheets can be viewed/downloaded at www.gradall.com
80884013 7-5
