USB-1608FS-Plus-OEM User's Guide
Pin Signal Name
1 CH0 IN
2 AGND
3 CH1 IN
4 AGND
5 CH2 IN
6 AGND
7 CH3 IN
8 AGND
9 CH4 IN
10 AGND
11 CH5 IN
12 AGND
13 CH6 IN
14 AGND
15 CH7 IN
16 AGND
17 RSVD
18 AGND
19 AGND
20 AGND
Table 16. Header connectors
Pin Signal Name
21 DIO0
22 GND
23 DIO1
24 GND
25 DIO2
26 GND
27 DIO3
28 GND
29 DIO4
30 GND
31 DIO5
32 GND
33 DIO6
34 GND
35 DIO7
36 SYNC
37 TRIG_IN
38 CTR
39 +VO
40 GND
22
Specifications
