INSTALLATION INSTRUCTIONS
(English)
WWW.BRINKAIRFORLIFE.NL
614411-K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Renovent Sky 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brink Renovent Sky 150

Summary of Contents for Brink Renovent Sky 150

  • Page 1 INSTALLATION INSTRUCTIONS (English) WWW.BRINKAIRFORLIFE.NL 614411-K...
  • Page 3 Children may not play with the appliance. If you need a new power cable, always order the replacement from Brink Climate Systems B.V. To prevent dangerous situations, a damaged mains connection must...

  • Page 4: Table Of Contents

    Table of contents page Delivery..................................Scope of delivery ............................... Accessories Renovent Sky 150 ..........................Application ................................4 Version..................................Technical information ..............................Connections and dimensions ............................ Fan graph .................................. Exploded view appliance ............................Operation .................................. Description................................. Bypass conditions..............................Frost protection................................Renovent Sky Plus version............................

  • Page 5: Delivery

    Scope of delivery Before starting installation of the heat recovery unit, check that it has been supplied complete and undamaged. The scope of delivery of the heat recovery unit Renovent Sky 150 includes the following components: 1: Heat recovery appliance 2: Wall mounting bracket kit;...

  • Page 6: Accessories Renovent Sky 150

    Chapter 1 Delivery Accessories Renovent Sky 150 Electric postheater 310730 Electric (extra) preheater 310740 Splitter RJ12 510472 sensor eBus surface-mounted 532126 Transmitter wireless remote control 2 positions (with. battery) 532170 Transmitter wireless remote control 4 positions (with. battery) 532171 Receiver wireless remote control (for battery version) 532172 Kit wireless remote control 2 positions (1 transmitter &...
  • Page 7 Silencer- / air distribution box 100 x 50 mm (12x) 423012 200 mm 660 mm 482 mm Silencer- / air distribution box 130 x 60 mm (12x) 423013 200 mm 660 mm 482 mm Servicetool 531961 Renovent Sky 150 614411-K...

  • Page 8: Application

    The Renovent Sky 150 comes ready to plug in with a 230 V low sound level mains plug. comes as standard with automatic bypass valve constant ow control The appliance comes not standard with a “Brink Air control”,...

  • Page 9: Version

    Ventilation capacity [m Static pressure [Pa] Housing emission [dB(A)] Sound power level Lw (A) Duct “from dwelling” [dB(A)] Duct “to dwelling” [dB(A)] In practice, the value may deviate 1 dB(A) as a result of measuring tolerances. Renovent Sky 150 614411-K...

  • Page 10: Connections And Dimensions

    1 To dwelling 2 To atmosphere 3 From dwelling 4 From atmosphere 5 Electric connections 6 Connection condensate discharge Fan graph Note: The value stated in the circle is the capacity per fan (in Watt) = [W] Renovent Sky 150 614411-K...

  • Page 11: Exploded View Appliance

    17 Service connector 18 Sleeve low voltage cable 19 Sleeve cable 230 V. postheater or extra preheater 20 Mains cable 230 V. 21 9-pole connector (only for Plus version) 22 Connector eBus Fall Protection front panel Renovent Sky 150 614411-K...

  • Page 12: Operation

    See §9 for more information on the connection possibilities of connectors X14 and X15. Hole for gland to be mounted by installer (for sleeve cable postheater/ extra preheater). Renovent Sky 150 614411-K...

  • Page 13: Installation

    The safety regulations for low-voltage installations. regulations must be complied with. The Renovent Sky 150 can directly be mounted to the wall or When mounting exible ducts, bear in mind that it must be ceiling using the mounting brackets supplied for that purpose.

  • Page 14: Placing The Appliance For Ceiling Mounting

    Chapter 5 Installation 1005 mm Click! Appliance disconnecting from mounting bracket Condensate discharge Renovent Sky 150 614411-K...

  • Page 15: Placing The Appliance For Wall Mounting

    . 2 5 m 5 0 5 m i n . 2 5 m m i n . 1 0 0 m 6 7 0 Click! Appliance disconnecting from mounting bracket Condensate discharge Renovent Sky 150 614411-K...

  • Page 16: Connecting The Condensate Discharge

    Before connecting the condensate discharge to the appliance, cannot be removed from the appliance for service pour water into the U-trap to create an air trap. Max 10 Nm 3/4” Detachable coupler Detachable coupler A > 60 mm Renovent Sky 150 614411-K...
  • Page 17 Chapter 5 Installation 60 mm Renovent Sky 150 614411-K...
  • Page 18 Chapter 5 Installation 60 mm Renovent Sky 150 614411-K...

  • Page 19: Electric Connections

    1375 W. the power plug when working on the appliance. The “Brink Air control” (option) must be connected to the eBus connector. This (detachable) 2-pole eBus connector is mounted on the outside of the appliance (see also §10.1).

  • Page 20: Display

    Settings in the “Brink Air control” software is set for the English language. In the setting menu “Brink Air of the Renovent Sky 150 can be called up and changed with Control”, §6.4.2, you can choose a language.

  • Page 21: View On Display

    This fault symbol appears when an appliance fault has occurred. When the text “Filter” appears on the “Brink Air control” display, the lters in the appliance must be cleaned or replaced. This indicates in what (preprogrammed) time interval the appliance is.

  • Page 22: Main Menu

    Chapter 6 Display Main menu Pressing the right-hand setting knob on the “Brink Air control” takes you to the 10.54 23/11/15 In this main menu you can use the right-hand setting knob to HRU-Ventilation 0 8 :0 0 17:0 0...

  • Page 23: Device Information Menu

    Airflow extract 0 m³/h Airflow extract 0 m³/h T dwelling 20.0 °C T dwelling 20.0 °C T atmosphere 15.3 °C T atmosphere 15.3 °C 0.0 % 0.0 % CO2-Sensor 1 CO2-Sensor 2 CO2-Sensor 3 CO2-Sensor 4 Renovent Sky 150 614411-K...

  • Page 24: Basic Settings Menu

    - Language Installer - Clock - Date - Backlight - Key lock Language In this menu you can choose a language; ex factory the “Brink Air Control” is set for the English language. 10.56 01.03.16 10.58 01.03.16 Basic settings Language Language...

  • Page 25: Installer Menu

    Min. PPM ebus CO2-Sensor 3 Max.PPM ebus CO2-Sensor 3 Min. PPM ebus CO2-Sensor 4 Max.PPM ebus CO2-Sensor 4 Offset flow Default position switch 10.59 01.03.16 Airflow - mode 0 30m³/h Standard: 30 m³/h Range: 0 or 30 m³/h Renovent Sky 150 614411-K...

  • Page 26: Fault

    Chapter 7 Fault Trouble shooting When the appliance control system detects a fault, it is indi- cated on the display of the “Brink Air control” with a spanner symbol, possibly together with a fault code. 10.59 01.03.16 Messages HRU-appliance History of errors 10.54...

  • Page 27: Display Codes

    If mode 2 of a multiple switch does not work, the modular connector of the multiple switch has been connected the wrong way round. Cut o one of the RJ connectors to the multiple switch and mount a new connector the other way round. Renovent Sky 150 614411-K...

  • Page 28: Maintenance

    ISO Coarse 60% (G4) HRU-Ventilation 0 8 :0 0 17:0 0 Filter 10.54 01.03.16 HRU-Ventilation Manual Filter ca. 10 sec. Supply air lter ISO Coarse 60% (G4) / ISO ePM 1 50% (F7) 10.54 01.03.16 HRU-Ventilation Manual Filter Renovent Sky 150 614411-K...
  • Page 29 Chapter 8 Maintenance Click! 10.54 01.03.16 HRU-Ventilation Manual Filter 5 sec. Filterreset red LED. 10.54 01.03.16 HRU-Ventilation 0 8 :0 0 17:0 0 Renovent Sky 150 614411-K...

  • Page 30: Maintenance Installer

    Maintenance installer Installer maintenance includes cleaning the heat exchanger and fans. Dependent on the conditions, this must done about once every three years. Swing open the front panel (can also be taken from the hinges, if required). Renovent Sky 150 614411-K...
  • Page 31 Chapter 8 Maintenance For ceiling mounting, carefully remove the condensate bin; there may still be some condensate left in the condensate Rinse the exchanger with hot water and a regular detergent. max. 45 ºC Renovent Sky 150 614411-K...
  • Page 32 Chapter 8 Maintenance Renovent Sky 150 614411-K...
  • Page 33 > ± 25 sec 10.54 23/11/15 HRU-Ventilation 08:00 17:00 Clic k! Filter reset; see §8.1 point 6 Press the Return key ( ) to leave any selected menu and the appliance will return to operating mode. Renovent Sky 150 614411-K...

  • Page 34: Elektric Diagram

    Motor bypass pre-heater temperature extract fan temperature switch board connector valve sensor sensor “Brink Air external sensor 0-10 V RH-sensor control” post-heater output 0-10V 24V. switch (optional) applicable post-heater input contact (optional) Renovent Sky 150 614411-K...

  • Page 35: Electric Connections Accessories

    1 or 2. The boost mode can be reset by putting the switch to setting 3 for longer than 2 seconds or by switching it to absence mode ( Renovent Sky 150 614411-K...

  • Page 36: Coupling Several Appliances

    Important: Because of polarity sensitivity, always connect contacts X1-1 to X1-1 and contacts X1-2 to X1-2. Never connect X1-1 and X1-2. A maximum of 10 appliances (1 Master + 9 Slave max.) 10.4 Connection RH (humidity)-sensor Cable sleeve Setting parameter 28 & 29 (§12) Renovent Sky 150 614411-K...

  • Page 37: Connection Postheater Or Extra Preheater

    ) The strain reliever to be installed by the installer (not supplied with the appliance) for feeding the 230 volt cable to the postheater or extra preheater. 230V 50Hz Connection 230V extra preheater 50Hz Setting parameter 11 (§12) Renovent Sky 150 614411-K...

  • Page 38: Connection Geo Heat Exchanger

    Chapter 10 Electric connections accessories 30°C 25°C Minimum temperature Maximum temperature To dwelling To atmosphere From dwelling 15°C From atmosphere 10°C 3°C 0°C Setting parameter 25, 26 & 27 (§12) Renovent Sky 150 614411-K...

  • Page 39: Connecting External Switch Contact

    Connections no. 3 and no. 4 standard 0-10 volt input; connections no. 1 and no. 2 can optionally be used as 0-10 volt input as well. Setting parameter 19, 20 & 21 (§12) Renovent Sky 150 614411-K...

  • Page 40: Service

    When ordering parts, in addition to the article code number (see exploded view), please state the type of the heat recovery appliance, the serial number, the year of production and the Appliance type : Renovent Sky 150 name of the part:: Serial number...
  • Page 41 The mains cable has a print connector. When replacing it, always order a replacement mains cable Brink Brink Climate Systems B. V. continuously strives after improvement of products and reserves the right to change the speci cations without prior notice.

  • Page 42: Setting Values

    2 (= Flow rate mode 1) Extract fan mode 3 (= Flow rate mode 2) 4 (= Flow rate mode 3) switching input 1 5 (= Multiple switch) 6 (= Maximum ow rate) 7 (= No extract fan activation) Renovent Sky 150 614411-K...
  • Page 43 25,0 °C 15,0 °C - 40,0 °C 0,5 °C (Above this temperature the valve opens.) OFF (= RH-sensor not active) RH-sensor ON (= RH-sensor active) +2 most sensitive Sensitivity 0 default setting RH-sensor RH-sensor -2 least sensitive Renovent Sky 150 614411-K...
  • Page 44 -sensor 4 Max. PPM eBus CO -sensor 4 1200 Flow correction 100% 90% - 110% Default position switch 0 - 1 Brink Connect function (exter- nal, Brink connect no RH sen- Brink Connect sor) Brink Connect (internal) Renovent Sky 150 614411-K...

  • Page 45: Erp Values

    Reference pressure di erence: 50 Pa Speci c Power Input (SEL)*: 0,27 Wh/m³ 1,0 in combination with manual switch 0,95 in combination with Brink Air Control Control factor: 0,85 in combination with 1 sensor 0,65 in combination with 2 or more sensors Internal...

  • Page 46: Declaration Of Conformity

    : 2017 + A11: 2020 EN 55014-2 : 2015 EN 61000-3-2 : 2014 EN 61000-3-3 : 2013 EN 60335-1 : 2012 EN 60335-2-80 : 2003 + A1: 2004 + A2: 2009 Staphorst, 23-09-21 A. Hans, Managing director Renovent Sky 150 614411-K...
