Elite 4 Burner Hybrid Barbecue
WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
Necessary Tools
Please check the pack contents before attempting to assemble this product. A full checklist of
components is given in this leaflet. If any components are missing, please contact the retailer
from whom you bought this product.
This product takes approximately 45 MINUTES
to assemble with 2 PEOPLE. The fittings pack
contains SMALL ITEMS which should be KEPT
AWAY FROM YOUNG CHILDREN. Read this
leaflet in full before commencing assembly.
GSS45MK
x 44
x 12
x 4
x 2
x 44
x 12
Carbon Monoxide Hazard
Using a barbecue inside can kill you,
it gives off Carbon Monoxide, which has no odour.
Never use a barbecue in enclosed spaces such as
a tent, home/building, vehicle or garage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elite GSS45MK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grillstream Elite GSS45MK

  • Page 1 Elite 4 Burner Hybrid Barbecue GSS45MK x 44 x 44 x 12 x 12 WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY Please read these instructions carefully and ensure that your barbecue is properly installed, assembled, maintained and serviced in accordance with these instructions. Failure to follow these instructions may result in serious injury and/or damage to property.
  • Page 2: Table Of Contents

    GSS46MK Contents Warning Information Page Location of your BBQ Page Connecting to the gas cylinder Page The hose and regulator assembly Page Testing for leaks Page Gas cylinder safety Page What is Propane Page Are all gas bottle gases the same Page How is it different from natural gas Page...
  • Page 3: Warning Information

    THE MANUFACTURER’S INSTALLATION INSTRUCTIONS, LOCAL GAS FITTING REGULATIONS AND MUNICIPAL BUILDING CODES. Think carefully when deciding on a location where you are to use your GRILLSTREAM BARBECUES, BBQ. The BBQ must not be installed under or on any combustible LEISUREGROW PRODUCTS LTD.
  • Page 4: Testing For Leaks

    GSS46MK SECURING THE HOSE AND REGULATOR ASSEMBLY WHAT IS PROPANE Type A) Screw on hose connection (Fig. 4) It is a fuel gas compressed until it turns to liquid, then stored in a bottle - The BBQ’s manifold connection is 1/4” Male Thread BSP or cylinder under pressure for easy transport.
  • Page 5: Lighting Your Bbq

    • off position and wait five minutes for any accumulated gas to clear out of the BBQ before repeating procedure. LIGHTING YOUR BBQ (cont.) Grillstream Grills fit directly on top of each other - do not offset them. lo position is obtained by turning the knob fully anti-clockwise - The...
  • Page 6: Hybrid System

    DIRECTIONS FOR USE - GAS: Your charcoal should now be lit and making the tell-tale popping and The beauty of the Grillstream Hybrid System is that there is no cracking sounds that indicate this. You should now turn off the burners additional assembly or conversion process required, whether you want completely and close your Barbecue Hood.
  • Page 7: Maintenance Of Your Bbq

    To clean the Grills effectively use the Grillstream cleaning brush which has been specially designed to quickly and effectively clean your Grillstream Grills. Rinse off with clean water and dry before returning to BBQ.
  • Page 8: Troubleshooting

    GSS46MK TROUBLESHOOTING A note on fire prevention: Most fires in outdoor BBQs are caused by a build up of greases and fat, IF BBQ FAILS TO OPERATE PROPERLY or gas connections which have not been secured properly. Remember - Stop, turn off gas at its source and turn all burner controls to • off to follow the manufacturer’s instructions on proper cleaning and - Do not smoke connection procedures.
  • Page 9: Exploded Diagram

    GSS46MK Page 9...
  • Page 10: Parts List For Gss45Mk

    Cabinet Side Panel - Right Grill Lifter Cabinet Rear Panel Warming Rack Corner Support Bracket Circular Griddle Plate Front Support Bar Grillstream Gastro Grill - Left Side Shelf Grillstream Gastro Grill - Right Cabinet Door Grillstream Grill - 230mm Grease Tray Page 10...
  • Page 11: Fittings List

    x 44 GSS46MK x 12 x 12 x 44 x 12 x 12 FITTINGS x 44 x 44 Part Part Part Part x 12 x 44 x 12 x 44 x 12 x 44 x 12 x 12 x 44 x 12 x 12 x 12...
  • Page 12: Assembly Instructions

    GSS46MK STEP 1 Push each of the Castors (5) into indicated holes in underside of Cabinet Base Panel (6) until you hear a click. Page 12...
  • Page 13 GSS46MK STEP 2 Part unscrew the bolts indicated from Cabinet Base Panel (6), slot the Cabinet Side Panels (7 & 8) into place and retighten bolts. Page 13...
  • Page 14 GSS46MK STEP 3 Insert and part tighten bolts (B) into Cabinet Side Panels (7 & 8). Slot Cabinet Rear Panel (9) into place and secure to Cabinet Base Panel (6) with Bolts (B). Now fully tighten bolts into Cabinet Side Panels (7 & 8). x 44 Part x 12...
  • Page 15 GSS46MK STEP 4 Part unscrew bolts indicated from Cabinet Side Panels (7 & 8) and Cabinet Base Panel (6). Slot Corner Support Brackets (10) in place and retighten bolts. Page 15...
  • Page 16 GSS46MK STEP 5 Insert Front Support Bar (11), ensuring magnets are at the bottom edge, and secure with Bolts (A). x 44 Part x 12 x 44 x 12 M4x12 Bolt Page 16...
  • Page 17 Unscrew and remove Wingnut and Washer from Thermometer (2). Thread Thermometer Spindle through Grillstream Logo Plate and then through hole indicated in Hood (1). Replace Washer and Wingnut. Note: Do not overtighten as this could lead to damaging of the hood.
  • Page 18 GSS46MK STEP 7 Secure cooking frame to side panels (7 & 8) using Bolts (B). Part x 44 x 12 M6x12 Bolt Page 18...
  • Page 19 GSS46MK STEP 8 Attach Side Shelf (12) to Cooking Frame (5) from the outside using Bolts (B). Part x 44 x 12 M6x12 Bolt Page 19...
  • Page 20 GSS46MK STEP 9 Further secure Side Shelf (12) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. x 44 Part x 12 x 44 x 12 M6x12 Bolt...
  • Page 21 GSS46MK STEP 10 Attach Side Burner Shelf (18) to Cooking Frame (5) from the outside using Bolts (B). Part x 44 x 12 M6x12 Bolt Page 21...
  • Page 22 GSS46MK STEP 11 Further secure Side Burner Shelf (18) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. Part x 44 x 12 M6x12 Bolt Part...
  • Page 23 GSS46MK STEP 12 Part unscrew bolts indicated on end of Side Burner Hose. Slot into bracket on underneath of Side Burner Shelf (18) and retighten bolts to secure. Slide Ignition Wire over Gas Ignition Electrode. Page 23...
  • Page 24 GSS46MK STEP 13 Attach Gas Connection Bracket to Side Panel (8) using Bolt (A). Now tighten the nut above the Gas Connection Bracket, this will help hold the hose in place when you attach the hose and regulator later. Note: The Gas Connection Bracket and Hose will be attached behind the Control Panel via cable tie, please cut the cable tie carefully to avoid damaging the components behind the Control Panel.
  • Page 25 GSS46MK STEP 14 Insert Door Spindles (C) into Cabinet Base Panel (6). Part x 44 Door Spindle Page 25...
  • Page 26 GSS46MK STEP 15 To fit Cabinet Doors (13) in place, first slide the hole on bottom of door over Door Spindle (C), depress spring-loaded catch on underside of Cooking Frame and position top of door until spring-loaded catch slides into top hole. Page 26...
  • Page 27 GSS46MK STEP 16 Attach Grease Cup Bracket (15) to underside of Grease Tray (14) using Bolts (A). Place Grease Cup (16) inside Grease Cup Bracket (15) and then slide underneath Cooking Frame ensuring it is level and on top of runners. Part x 44 M4x12 Bolt...
  • Page 28 Cooking Frame. Leg tabs from bottom Grillstream Grills and Grillstream Gastro Grills should rest on lip at back of Cooking Frame with the logo tab at the front. Top Grillstream Grills should sit directly on top of the bottom Grills.
  • Page 29 Attach Bottle Opener (21) to front of Control Panel using bolts supplied. Hook Grillstream Fat Cup (20) over holes in Side Panel (8). This should be located directly below the spout of Fat Channel (19) to catch fat and meat juices channelled from the Grillstream system.
  • Page 30 GSS46MK STEP 19 Your Grillstream barbecue is now fully assembled and you are ready to connect the Gas Cylinder (see page 3 for more information). Please ensure you perform the gas leak check before operating. Page 30...
  • Page 31: Leak Test

    GSS46MK TESTING YOUR BBQ TESTING FOR LEAKS - DO THIS BEFORE USING YOUR BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
  • Page 32 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Grillstream Barbecues Part of the LeisureGrow Group Dewmead Farm, New Inn Road, Hinxworth, Hertfordshire SG7 5HG, United Kingdom. Tel: +44 (0)1462 744500 E-mail:salessupport@leisuregrow.com...
