Grillstream GSG66SS Pre-Assembly Preparation

Grillstream GSG66SS Pre-Assembly Preparation

6 burner roaster

Advertisement

Thank you for purchasing this barbecue. Please read the instructions carefully before use to ensure
safe and satisfactory operation of this product. Please keep these instructions for future reference.
Pre-assembly preparation
WARNING! FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
If you have any questions concerning the assembly or operation of this barbecue, please contact your local
stockist.
Before using your BBQ please test for any gas leaks following the guidance given in this instruction manual
Necessary Tools
(Not supplied)
4x AA Batteries required (Not supplied)
This product takes approximately 60 MINUTES to assemble with 2 PEOPLE. The fittings pack contains SMALL ITEMS which
should be KEPT AWAY FROM YOUNG CHILDREN
Please check the pack contents before attempting to assemble this product. A full checklist of components is given on this
leaflet. If any components are missing, please contact the retailer from whom you bought this product.
Read this leaflet in full before commencing assembly.
6 Burner Roaster
YOU MUST CHECK FOR GAS LEAKS
BEFORE USING YOUR BARBECUE.
1
Carbon Monoxide Hazard
Using a barbecue inside can kill you.
It gives off Carbon Monoxide, which
Never use a barbecue in enclosed
spaces such as a tent, home/building,
vehicle or garage.
SEE PAGE 2 AND/OR PAGE 33
GSG66SS
!
WARNING
has no odour.
