Grillstream Stealth Manual

6 burner barbecue
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
x 44
WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
Necessary
Tools
Please check the pack contents before attempting to assemble this product. A full checklist of
components is given in this leaflet. If any components are missing, please contact the retailer from
whom you bought this product.
This product takes approximately 60 MINUTES
to assemble with 2 PEOPLE. The fittings pack
contains SMALL ITEMS which should be KEPT
AWAY FROM YOUNG CHILDREN. Read this
leaflet in full before commencing assembly.
Stealth 6 Burner Barbecue
GSH65MK
x 4
x 12
x 12
x 2
x 44
Carbon Monoxide Hazard
Using a barbecue inside can kill you,
it gives off Carbon Monoxide, which has no odour.
Never use a barbecue in enclosed spaces such as
a tent, home/building, vehicle or garage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stealth and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grillstream Stealth

Summary of Contents for Grillstream Stealth

  • Page 1 Stealth 6 Burner Barbecue GSH65MK x 44 x 12 x 44 x 12 WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY Please read these instructions carefully and ensure that your barbecue is properly installed, assembled, maintained and serviced in accordance with these instructions.

  • Page 2: Table Of Contents

    GSH65MK Contents Warning Information Page Location of your BBQ Page Connecting to the gas cylinder Page The hose and regulator assembly Page Testing for leaks Page Gas cylinder safety Page What is Propane Page Are all gas bottle gases the same Page How is it different from natural gas Page...

  • Page 3: Warning Information

    - Never alter or modify the regulator or gas supply assembly. Propane - 2.75 kPa Universal LPG - 2.75 kPa LOCATION OF YOUR BBQ IMPORTANT - BBQS MUST BE INSTALLED IN ACCORDANCE WITH GRILLSTREAM BARBECUES, THE MANUFACTURER’S INSTALLATION INSTRUCTIONS, LOCAL LEISUREGROW PRODUCTS LTD. 0539-25 2575-25 GAS FITTING REGULATIONS AND MUNICIPAL BUILDING CODES.

  • Page 4: Testing For Leaks

    GSH65MK SECURING THE HOSE AND REGULATOR ASSEMBLY GAS CYLINDER SAFETY - Always change over a gas cylinder away from any possible source Quick release connection (Fig. 4) of ignition in a well ventilated area - The BBQ’s manifold connection is a quick release connector - Do not smoke whilst handling gas cylinders - Gently pull back the movable section on the manifold, insert hose - Never store gas cylinder indoors...

  • Page 5: Lighting Your Bbq

    • off position and wait five minutes for any accumulated gas to clear out of the BBQ before repeating procedure. LIGHTING YOUR BBQ (cont.) Grillstream Grills fit directly on top of each other - do not offset them. lo position is obtained by turning the knob fully anti-clockwise - The...

  • Page 6: Hybrid System

    You should now turn off the burners DIRECTIONS FOR USE - GAS: completely and close your Barbecue Hood. The beauty of the Grillstream Hybrid System is that there is no additional assembly or conversion process required, whether you want STEP 4: to use it as a Charcoal Barbecue or Gas Barbecue.

  • Page 7: Maintenance Of Your Bbq

    To clean the Grills effectively use the Grillstream cleaning brush which has been specially designed to quickly and effectively clean your Grillstream Grills. Rinse off with clean water and dry before returning to BBQ.

  • Page 8: Troubleshooting

    Ignition tube and clear out any debris inside (fig C) WARRANTY All of our Grillstream BBQs and accessories are built to last. Our materials are carefully considered with longevity and safety in mind, the technology used in our products is second to none, and all of this is backed up with our friendly customer care team who are on hand for advice and assistance.

  • Page 9: Exploded Diagram

    GSH65MK Page 9...

  • Page 10: Parts List

    Side Shelf Fascia - Left Hybrid Flame Tamer Side Shelf Support Bracket - Left Rear Flame Tamer Side Shelf Support Bracket – Left Front Grillstream Grill – 230mm Side Burner Trivet Grillstream Griddle – 190mm Side Burner Warming Rack Side Burner Lid...

  • Page 11: Fittings List

    GSH65MK FITTINGS Part Part Part Part x 44 x 12 x 44 x 12 x 44 x 12 x 12 Self-Tapping M6 x 14 Bolt Door Spacer Screw 9mm M4 x 12 SS Bolt Part Part Part Part Self-Tapping Door Spindle Screw 12mm M4 x 12 Bolt M6 Washer...
  • Page 12 GSH65MK STEP 1 Push each of the Locking Castors (5) into indicated holes in underside of Cabinet Base Panel (6) until you hear a click. Page 12...
  • Page 13 GSH65MK STEP 2 Part unscrew the bolts indicated from Cabinet Base Panel (6), slot the Cabinet Side Panels (7 & 8) into place and retighten bolts. Page 13...
  • Page 14 GSH65MK STEP 3 Insert and part tighten 2 x Bolt (A) into Cabinet Side Panels (7 & 8). Slot Cabinet Rear Panel (9) into place and secure to Cabinet Base Panel (6) with 2 x Bolt (A). Now fully tighten bolts into Cabinet Side Panels.
  • Page 15 GSH65MK STEP 4 Part unscrew bolts indicated from Cabinet Side Panels (7 & 8) and Cabinet Base Panel (6). Slot Corner Support Brackets (11) in place and retighten bolts. Page 15...
  • Page 16 GSH65MK STEP 5 Insert Front Support Bar (10), ensuring magnets are at the bottom edge, and secure with 4 x Bolt (G). Part M4 x 12 Bolt Page 16...
  • Page 17 Unscrew and remove Wingnut and Washer from Thermometer (3). Thread Thermometer Spindle though Grillstream Logo Plate (4) and then through Hood (1). Replace Washer and Wingnut. Carefully lower Cooking Frame onto Cabinet, ensuring fixing lugs are on the outside and that no wires of hoses are trapped between Cooking Frame and Cabinet.
  • Page 18 GSH65MK STEP 7 Secure Cooking Frame to Cabinet Side Panels (7 & 8) using 4 x Bolt (A). Part M6 x 14 Bolt Page 18...
  • Page 19 GSH65MK STEP 8 Lift Side Burner Lid (18) and push spindle towards spring. Remove spindle from opposite end then remove Side Burner Lid, Trivet (16) and Side Burner (17) from Side Burner Side Shelf (12). Page 19...
  • Page 20 GSH65MK STEP 9 Attach Side Shelf Support Bracket – Left Rear (14) to inside rear of Side Burner Side Shelf (12) with 2 x Bolt (G). Now attach Side Shelf Fascia – Left (13) to front of Side Burner Side Shelf using 1 x Bolt (G) through far left hole and 2 x Self-Tapping Screw (F).
  • Page 21 GSH65MK STEP 10 Reinstall the Side Burner (17) and Trivet (16) into Side Burner Side Shelf (12). Now reinstall the Side Burner Lid (18) by pushing the spring end of the spindle through the hole in the lid and side shelf, compressing the spring to allow you to thread the opposite end through the opposite hole.
  • Page 22 GSH65MK STEP 11 Part unscrew the two bolts indicated on side of Cooking Frame and slot Side Burner Side Shelf (12) in place and retighten the bolts. Now further secure at the rear using 1 x Bolt (A). Attach Side Shelf Fascia - Left (13) at the front to side of Control Panel using 2 x Bolt (G).
  • Page 23 GSH65MK STEP 12 Attach Warming Rack Clip – Left (23) to top lip of Cooking Frame using 1 x Bolt (A) and 1 x Washer (H). Now further secure Side Burner Side Shelf from inside of Cooking Frame using 2 x Bolt (A) and 2 x Washer (H).
  • Page 24 GSH65MK STEP 13 Insert wire from LED Circuit Board (41) through hole in Control Knob Bezel (40) and push circuit board into place, ensuring hole and cutout match up with those on the bezel. Part screw in bolt from separate bolt pack on Side Burner Control Spindle and slide through Side Shelf Fascia - Left (13) and Control Knob Bezel from behind.
  • Page 25 GSH65MK STEP 14 Part unscrew bolts indicated on end of Side Burner Hose. Slot into bracket in underneath of Side Burner (17) and retighten bolts to secure. Slide Ignition Wire over Gas Ignition Electrode. Page 25...
  • Page 26 GSH65MK STEP 15 Attach Side Shelf Support Bracket – Right Rear (21) to inside rear of Side Shelf (19) with 2 x Bolt (G). Now attach Side Shelf Fascia – Right (20) to front of Side Shelf using 1 x Bolt (G) through far right hole and 2 x Self-Tapping Screw (F).
  • Page 27 GSH65MK STEP 16 Part unscrew the two bolts indicated on side of Cooking Frame and slot Side Shelf (19) in place and retighten the bolts. Now further secure at the rear using 1 x Bolt (A). Attach Side Shelf Fascia - Right (20) at the front to side of Control Panel using 2 x Bolt (G).
  • Page 28 GSH65MK STEP 17 Attach Warming Rack Clip – Right (24) to top lip of Cooking Frame using 1 x Bolt (A) and 1 x Washer (H). Now further secure Side Shelf from inside of Cooking Frame using 2 x Bolt (A) and 2 x Washer (H).
  • Page 29 GSH65MK STEP 18 Insert Door Spindles (E) into holes at front of Cabinet Base Panel (6). Part Door Spindle Page 29...
  • Page 30 GSH65MK STEP 19 Pass Spacers (B) and Self-Tapping Screws (C) through Cabinet Doors (26) and screw into Door Handles (25). To fit Cabinet Doors in place, first slide the hole on bottom of door over Door Spindle (E), depress spring-loaded catch on underside of Cooking Frame and position top of door until spring-loaded catch slides into top hole.
  • Page 31 GSH65MK STEP 20 Connect Battery Wire to the Battery Pack (27). The reverse of the Battery Pack is magnetic and should attach to Cabinet Side Panel - Right (8) in area shown. Insert 4 x AA Batteries (not supplied) into Battery Pack. The On/Off switch for the LED Control Knob function is located to the left of the control panel.
  • Page 32 GSH65MK STEP 21 Attach Grease Cup Bracket (29) to underside of Grease Tray (28) using 2 x Bolt (G). Place Grease Cup (30) inside Grease Cup Bracket and then slide underneath Cooking Frame ensuring it is level and on top of runners. Part M4 x 12 Bolt Page 32...
  • Page 33 GSH65MK STEP 22 Attach Tool Hook Rack (31) by slotting it over the lip on the underside of the Side Burner Side Shelf (12) and securing from below using 1 x Bolt (A). Part M6 x 14 Bolt Page 33...
  • Page 34 GSH65MK STEP 23 Attach Bottle Opener (32) to side of Side Shelf Fascia – Right (20) using 2 x Bolt (D). Part M4 x 12 SS Bolt Page 34...
  • Page 35 GSH65MK STEP 24 Hook Grillstream Fat Cup (33) over holes in Cabinet Side Panel - Right (8). This should be located directly below the spout of Fat Channel (34) to catch fat and meat juices channelled from the Grillstream system.
  • Page 36 GSH65MK STEP 25 Insert back legs of Warming Rack (39) into channel on Warming Rack Clips. Angle Warming Rack forwards and insert front legs into holes located on Cooking Frame (5). To operate, lift front legs out of holes in Cooking Frame and tilt Warming Rack upwards. Pull Warming Rack forwards slightly so back legs are inline with vertical track and slide downwards.
  • Page 37 Place Grillstream Grills (37) and Griddle (38) into Cooking Frame. Leg tabs from bottom Grillstream Grills and Griddle should rest on lip at back of Cooking Frame. Top Grillstream Grills should sit directly on top of the bottom Grill. Griddle should be positioned above standard Flame Tamer.

  • Page 38: Leak Test

    GSH65MK TESTING YOUR BBQ TESTING FOR LEAKS - DO THIS BEFORE USING YOUR BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
  • Page 39 GSH65MK Page 39...
  • Page 40 GSH65MK PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Grillstream Barbecues Part of the LeisureGrow Group Dewmead Farm, New Inn Road, Hinxworth, Hertfordshire SG7 5HG, United Kingdom. Tel: +44 (0)1462 744500 Page 40 E-mail:salessupport@leisuregrow.com...
