Carbon 3 Burner Hybrid Barbecue
WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
Necessary
Tools
Please check the pack contents before attempting to assemble this product. A full checklist of
components is given in this leaflet. If any components are missing, please contact the retailer from
whom you bought this product.
This product takes approximately 90 MINUTES
to assemble with 2 PEOPLE. The fittings pack
contains SMALL ITEMS which should be KEPT
AWAY FROM YOUNG CHILDREN. Read this
leaflet in full before commencing assembly.
GCB35K
Carbon Monoxide Hazard
Using a barbecue inside can kill you,
it gives off Carbon Monoxide, which has no odour.
Never use a barbecue in enclosed spaces such as
a tent, home/building, vehicle or garage.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Grillstream GCB35K
Summary of Contents for Grillstream GCB35K
- Page 1 Carbon 3 Burner Hybrid Barbecue GCB35K WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY Please read these instructions carefully and ensure that your barbecue is properly installed, assembled, maintained and serviced in accordance with these instructions. Failure to follow these instructions may result in serious injury and/or damage to property.
-
Page 2: Table Of Contents
Lighting your BBQ Page Using your BBQ Page Hybrid System Page Maintenance of your BBQ Page Troubleshooting Page Warranty Page Exploded diagram Page Parts list for GCB35K Page Fittings list Page Assembly instructions Page 12-36 Leak Test Page Page 2... -
Page 3: Warning Information
GCB35K CONNECTING THE GAS CYLINDER WARNING INFORMATION There are two different types of gas that can be used on your gas BBQ - Read this Operating Manual before use. depending on where you live, that being either butane or propane gas. -
Page 4: Testing For Leaks
GCB35K SECURING THE HOSE AND REGULATOR ASSEMBLY GAS CYLINDER SAFETY Quick release connection (Fig. 4) - Always change over a gas cylinder away from any possible source - The BBQ’s manifold connection is a quick release connector of ignition in a well ventilated area... -
Page 5: Lighting Your Bbq
• OFF position and wait five minutes for any accumulated gas to clearout of the BBQ before repeating procedure. CONTROLLING YOUR BBQ (GAS-MODE) Grillstream Grills fit directly on top of each other - do not offset them. lo position is obtained by turning the knob fully anti-clockwise - The... -
Page 6: Hybrid System
DIRECTIONS FOR USE - GAS: cracking sounds that indicate this. You should now turn off the burners The beauty of the Grillstream Hybrid System is that there is no completely and close your Barbecue Hood. additional assembly or conversion process required, whether you want to use it as a Charcoal Barbecue or Gas Barbecue. -
Page 7: Maintenance Of Your Bbq
To clean the Grills effectively use the Grillstream cleaning brush which has been specially designed to quickly and effectively clean your Grillstream Grills. Rinse off with clean water and dry before returning to BBQ. -
Page 8: Troubleshooting
- Empty the fat cup responsibly after each use. burners over orifices and test again WARRANTY All of our Grillstream BBQs and accessories are built to last. Our materials are carefully considered with longevity and safety in mind, the technology used in our products is second to none, and all of this is backed up with our friendly customer care team who are on hand for advice and assistance. -
Page 9: Exploded Diagram
GCB35K Page 9... -
Page 10: Parts List For Gcb35K
Side Burner Control Knob Bezel Crossfire Assembly Towel Holder Electrode Set, Main Burner Side Shelf Hybrid Flame Tamer Tool Rack Grillstream Grill Grillstream Fat Cup Holder Warming Rack Grillstream Fat Cup Trolley Back Panel Fat Channel Heat Shield Trolley Side, Left Grease Cup hook... -
Page 11: Fittings List
GCB35K FITTINGS Part Part Part Part 1/4” Bolt NO.10 Bolt Gas Bottle Wheel Spacer Support Bolt Part Part Part Part x 44 x 12 x 44 x 12 x 44 x 12 x 44 x 12 Wheel Washer Split Pin NO.8 Bolt... - Page 12 GCB35K STEP 1 Attach Trolley Shelf (EC) to Trolley Side - Left (EA) using 5 x Bolt (1). Repeat for second Trolley Shelf. Part 1/4” Bolt Page 12...
- Page 13 GCB35K STEP 2 Attach Trolley Shelf (EC) to Trolley Side - Right (EB) using 7 x Bolt (1). Repeat for second Trolley Shelf. Part 1/4” Bolt Page 13...
- Page 14 GCB35K STEP 3 Slide 1 x Wheel (FB) and Wheel Spacer (4) onto Wheel Axle (FA). Now slide Wheel Axle through both legs of Trolley Side - Left (EA). Now slide second Wheel Spacer (4), Wheel (FB) and Washer (5) onto Wheel Axle, securing in place using 1 x Split Pin (6). Now carefully affix 2 x Wheel Cap (FC) onto both wheels.
- Page 15 GCB35K STEP 4 Carefully lower Cooking Frame (BA) onto Trolley Side - Left and Right (EA & EB) and secure in place using 6 x Bolt (1). Part 1/4” Bolt Page 15...
- Page 16 GCB35K STEP 5 Connect Trolley Back Panel (BH) to reverse of Cooking Frame (BA) and Trolley Side - Left and Right (EA & EB) using 6 x Bolt (1). Part 1/4” Bolt Page 16...
- Page 17 GCB35K STEP 6 Part unscrew bolts on side of Cooking Frame as indicated and hook Side Burner Shelf (DA) in place. It will be further secured in the next step. Page 17...
- Page 18 GCB35K STEP 7 Secure Side Burner Shelf (DA) in place using 2 x Bolt (2) at the front and 1 x Bolt (1) at the back. Leave all bolts loose until Step 10. Part Part 1/4” Bolt NO.10 Bolt Page 18...
- Page 19 GCB35K STEP 8 Remove nut indicated, located on underside of Side Burner Shelf (DA). Keep it handy as you will need it for the next step. Page 19...
- Page 20 GCB35K STEP 9 Slot Side Burner Support Brace (DC) into place as shown. Now reinstall the nut removed in previous step. Page 20...
- Page 21 GCB35K STEP 10 Secure Side Burner Shelf (DA) using 1 x Bolt (1) and Washer (9). Now tighten all bolts installed in Step 7. Part Part 1/4” Bolt AI Washer Page 21...
- Page 22 GCB35K STEP 11 Move Side Burner Valve into place behind Side Burner Shelf, pushing Control Spindle through the hole located in the fascia. Hold Side Burner Control Knob Bezel in place and secure Bezel and Valve in using 2 x Bolt (7).
- Page 23 GCB35K STEP 12 Push Control Knob (DH) onto spindle. Page 23...
- Page 24 GCB35K STEP 13 Lift lid on Side Burner Shelf and insert Side Burner (DF). Ensure opening of Side Burner tube sits over the Burner Nozzle on rear of Side Burner Valve. Secure in place using Wing Nut (8). Slide Side Burner Ignition Cable (DG) over Electrode on underside of Side Burner (DF).
- Page 25 GCB35K STEP 14 Insert Side Burner Trivet (DE) into Side Burner Shelf as shown. Page 25...
- Page 26 GCB35K STEP 15 Part unscrew bolts on side of Cooking Frame as indicated and hook Side Shelf (DK) in place. It will be secured in the next step. Page 26...
- Page 27 GCB35K STEP 16 Secure Side Shelf (DK) in place using 2 x Bolt (2) at the front and 2 x Bolt (1) at the bottom. Now tighten all bolts in this and the previous step. Part Part 1/4” Bolt NO.10 Bolt...
- Page 28 GCB35K STEP 17 Lift Hood and insert Hybrid Flame Tamers (BE) and Flame Tamer (BL). Both types of Flame Tamer should sit directly above the burner tubes. Page 28...
- Page 29 GCB35K STEP 18 Insert Fat Channel (DO) into Cooking Frame by first sliding the thin end (spout) through right-hand side of Cooking Frame and then slotting the front lip of the Fat Channel between the Cooking Frame and Control Panel.
- Page 30 GCB35K STEP 19 Place Grillstream Grills (BF) Griddle Plate (BM) into Cooking Frame. Leg tabs from both types of Grill should rest on lip at back of Cooking Frame. Top Grills should sit directly on top of the bottom Grill.
- Page 31 GCB35K STEP 20 Insert Fat Cup Holder (DM) into Side Shelf Fascia - Right and secure in place using 3 x Countersunk Bolt (11). Now insert Fat Cup (DN) into Fat Cup Holder (DM). Part Countersunk Bolt Page 31...
- Page 32 GCB35K STEP 21 Insert Warming Rack (BG) into place, ensuring leg tabs at the back slot into holes located in the rear of the Cooking Frame (BA). Front legs rest in cutouts located in either side of the Cooking Frame (BA).
- Page 33 GCB35K STEP 22 Drop Grease Cup (BK) into circular section of Grease Cup Hook (BJ). Now hook top of Grease Cup Hook (BJ) into cutout section of Heat Shield located below the Cooking Frame. Page 33...
- Page 34 GCB35K STEP 23 Attach one end of the Gas Bottle Support (EF) to rear leg of Trolley Side - Left (EA) using 1 x Gas Bottle Support Bolt (3). Hook the other end over the Clamping Knob pre-installed on front leg of Trolley Side - Left.
- Page 35 GCB35K STEP 24 Attach Hose Clip (10) to front leg of Trolley Side – Left (EA) using 1 x Bolt (1) clamping the Gas Hose neatly in place. Part Part 1/4” Bolt Hose Clip Page 35...
- Page 36 GCB35K TESTING YOUR BBQ TESTING FOR LEAKS - DO THIS BEFORE USING YOUR BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
-
Page 37: Leak Test
GCB35K Page 37... - Page 38 GCB35K PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Grillstream Barbecues Part of the LeisureGrow Group Dewmead Farm, New Inn Road, Hinxworth, Hertfordshire SG7 5HG, United Kingdom. Tel: +44 (0)1462 744500 Page 38 E-mail:consumer@leisuregrow.com...
