- Page 1 MOVING WATER FORWARD, SINCE 1968 LEDS19 Stainless Steel WaterGlow Lighting Operation & Maintenance Manual Document number 884050 Document version 2021.2.1 800 Deere Rd. Prescott, WI 54021 | 715.262.4488 | sales@kascomarine.com | kascomarine.com LEDS19 STAINLESS STEEL WATERGLOW LIGHTING MANUAL...
-
Page 2: Table Of Contents
Safety First ..........................2 Tools Required ........................2 Parts Included .........................3 Mounting Instructions ......................4 Maintenance Recommendations ..................7 Troubleshooting Tips ......................7 Warranty ..........................9 Repair ............................9 Non-Warranty Repairs ......................10 Repair Contact Form ......................11 QUESTIONS? 715.262.4488 kascomarine.com | sales@kascomarine.com LEDS19 STAINLESS STEEL WATERGLOW LIGHTING MANUAL... -
Page 3: Safety First
Please read and follow these important instructions to help ensure your safety and the quality performance of your Kasco equipment. • LEDS19 kit is 120Vac and MUST be plugged into a GFCI protected receptacle or GFCI protected field ter- minal connections. •... -
Page 4: Parts Included
Colored lens kit (4 colors) 345559 LEDS19 fixture LEDS19 1/4”-20 x 1/2” hex screw 451126 1/4” lock washer 840537 S19 bracket, clip 346069 Snap-on light clip 361445 Cable tie (not pictured) 415038 *Double quantities for 6-light kit LEDS19 STAINLESS STEEL WATERGLOW LIGHTING MANUAL... -
Page 5: Mounting Instructions
(B) of your choice. Place the lens inside the lens cap (A) making sure the 3 flaps are holding the lens in place. Repeat this step for all lens caps. Continue to Step 3. No gap Flaps behind lens LEDS19 STAINLESS STEEL WATERGLOW LIGHTING MANUAL... - Page 6 Make sure the fixture and lens are clean before installing the lens cap. Repeat for all fixtures. 4. Slide bracket into the top flange on the snap-on clip (G) until it clicks into place and is secure. LEDS19 STAINLESS STEEL WATERGLOW LIGHTING MANUAL...
- Page 7 Upon installation of the assem- bled unit, connect the light kit to a field-installed GFCI protected outlet and timer. Remember: LEDS19 fixtures MUST be properly submerged (to mark on housing) to avoid overheating...
-
Page 8: Maintenance Recommendations
The following maintenance procedures can be utilized to ensure many years of quality performance from your Kasco fountain and light kit and reduce the need for more costly repair work. Note that the LED fixtures are sealed and do not require any maintenance other than cleaning. Do not attempt to open light fixtures, as this will void the warranty. - Page 9 TROUBLESHOOTING TIPS (CONT.) • Kasco C-25, C-85, and C-95 control panels have a photo eye on the left side of the enclosure exterior. This photo eye measures ambient light. To activate, the photo eye must not measure any ambient light for at least several minutes.
-
Page 10: Warranty
Warranty period: LED3S19, LED6S19 = 3 year Limited Warranty. Kasco® Marine, Inc. warrants this light kit to be free from defects in material or workmanship under normal use and service. The Kasco Marine, Inc. obligation under this warranty is limited to replacing or repairing free of charge any defective part within the warranty period from the date of shipment. -
Page 11: Non-Warranty Repairs
Most failed equipment can be repaired at substantially lower costs than replacement with new. If your light kit requires repair and is no longer covered under warranty, please contact Kasco Marine or your local distributor for available options. Please ship according to the instructions above. -
Page 12: Repair Contact Form
Back to Contents REPAIR CONTACT FORM • Kasco requires that all equipment sent for repair MUST be accompanied by this form and marked to Repairs attention. Kasco Marine • Unit should be cleaned before shipping. 800 Deere Road • Kasco is NOT responsible for shipping damage accrued in Prescott, WI 54021 return shipment.
