  • Page 1 M-200 and M-600 Appliance Hardware Reference docs.paloaltonetworks.com...
  • Page 2 Alto Networks. A list of our trademarks can be found at www.paloaltonetworks.com/company/ trademarks.html. All other marks menoned herein may be trademarks of their respecve companies. Last Revised August 2, 2018 M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 3: Table Of Contents

    M-200 and M-600 Appliance Port LEDs................23 Install M-200 or M-600 Appliance in an Equipment Rack.....25 Install the M-200 Appliance in a 19” Equipment Rack............ 26 Install the M-600 Appliance in a 19” Equipment Rack............ 29 Connect Power to an M-200 or M-600 Appliance........33 Connect AC Power to an M-200 or M-600 Appliance............34...
  • Page 4 Table of Contents M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 5: Before You Begin

    Before You Begin Read the following topics before you install or service a Palo Alto Networks next- ® generaon firewall or appliance. The following topics apply to all Palo Alto Networks firewalls and appliances except where noted. > Upgrade/Downgrade Consideraons for Firewalls and Appliances >...

  • Page 6: Upgrade/Downgrade ConsideraOns For Firewalls And Appliances

    If the value the downgrade. If the is less than 20, then value is less than 20, contact support for then contact support for assistance. assistance. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 7: Tamper Proof Statement

    • The integrity of the warranty label on the firewall or appliance is not compromised. (PA-7000 Series firewalls only) PA-7000 Series firewalls are modular systems and therefore do not include a warranty label on the firewall. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 8: Third-Party Component Support

    Before You Begin Third-Party Component Support Before you consider installing third-party hardware, read the Palo Alto Networks Third-Party Component Support statement. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 9: Product Safety Warnings

    • I/O ports are intended for intra-building connecons only and not intended for OSP (Outside Plant) connecons or any network connecons subject to external voltage surge events. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 10 Toutefois, vous devez le faire dans les 45 secondes et vous ne pouvez remplacer qu’un roir à la fois, sinon le circuit de protecon thermique arrêtera le pare-feu. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 11 (de service) qu'à l'aide d'un oul spécial, cadenas ou clé, ou autre disposif de sécurité, et qui est contrôlée par l'autorité responsable du site. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 12 • A suitably-rated DC mains disconnect device must be provided as part of the building installaon. French Translaon: Un interrupteur d'isolement suffisant doit être fourni pendant l'installaon du bâment. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 13: M-200 And M-600 Appliance Overview

    Management-only mode, Panorama Log Collector mode, or PAN-DB Private Cloud mode (M-600 only). First Supported Soware Release: Panorama 8.1 The following topics describe the hardware features of the M-200 and M-600 appliances. > M-200 Appliance Front Panel > M-200 Appliance Back Panel >...
  • Page 14 M-200 and M-600 Appliance Overview M-200 Appliance Front Panel The following image shows the front panel of the M-200 appliance and the table describes each front-panel component. Item Component Descripon System drive 240GB solid-state drive (SSD) used to store the operang system files and system logs.
  • Page 15 Hard-disk drives (HDDs) Disk drive bays and HDDs used for log storage. By default, the M-200 ships with four HDDs installed in drive bays A1/A2 and B1/B2. Each pair of drives are in a RAID 1 configuraon (A1-A2 is a RAID 1 pair and B1-B2 is a RAID 1 pair).
  • Page 16 M-200 and M-600 Appliance Overview M-200 Appliance Back Panel The following image shows the back panel of the M-200 appliance and the table describes each back-panel component. Item Component Descripon Power supplies Use the AC power supply inputs to connect power to the appliance.
  • Page 17 UID LED that illuminates bright blue when you push the UID buon on the front of the appliance. For informaon on using the UID feature, see the UID buon descripon for the M-200 Appliance Front Panel. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 18 (1Hz)—A fan failure occurred. • Blinking red at the rate of one blink every four seconds (.25Hz)—One of the two power supplies is not providing power to the appliance (possibly M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 19 Hard-disk drive (HDD) LEDs Status LEDs—two for each log drive: • Top LED—Flashing blue indicates drive acvity. • Boom LED—Solid red indicates a log drive failure. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 20 If the appliance is in PAN-DB mode, refer to the appropriate release-specific PAN-OS Administrators Guide. ® USB ports Not used. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 21 The UID buon is very small and is located to the le of the UID LED. Use a small object, such as a paper clip, to press the buon. M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 22 ™ Technical Documentaon Portal for the release running on your appliance. If the appliance is in PAN-DB mode, refer to the appropriate release- specific PAN-OS Administrators Guide. ® M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
  • Page 23 M-200 and M-600 Appliance Overview M-200 and M-600 Appliance Port LEDs The following table describes how to interpret the status of port LEDs on M-200 and M-600 appliances. The only difference between the port LEDs on these appliances is that the M-600 appliance has two addional SFP+ port LEDs.
  • Page 24 M-200 and M-600 Appliance Overview M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 25: Install M-200 Or M-600 Appliance In An Equipment Rack

    Install M-200 or M-600 Appliance in an Equipment Rack The M-200 and M-600 appliances ship with a four-post rack kit for installaon in a 19” four-post equipment rack. > Install the M-200 Appliance in a 19” Equipment Rack > Install the M-600 Appliance in a 19” Equipment Rack...

  • Page 26: Install The M-200 Appliance In A 19" Equipment Rack

    Install M-200 or M-600 Appliance in an Equipment Rack Install the M-200 Appliance in a 19” Equipment Rack The following procedure describes how to install the M-200 appliance in a four-post equipment rack. The rack kit includes the hardware required to install the appliance in most equipment racks.
  • Page 27 Install M-200 or M-600 Appliance in an Equipment Rack holes, and then release the buons to secure the rails to the rack. The following image shows the right side of the rack if you are facing the front of the rack.
  • Page 28 Install M-200 or M-600 Appliance in an Equipment Rack the appliance and then connue to slide the appliance in to the rack unl the front of the appliance is flush with the front of the rack. The inner-rail release clips are shown in step 1.

  • Page 29: Install The M-600 Appliance In A 19" Equipment Rack

    Install M-200 or M-600 Appliance in an Equipment Rack Install the M-600 Appliance in a 19” Equipment Rack The following procedure describes how to install the M-600 appliance in a four-post equipment rack. The rack kit includes the hardware required to install the appliance in most equipment racks.
  • Page 30 Install M-200 or M-600 Appliance in an Equipment Rack (with washers) for each rail. The following image shows the right side of the rack if you are facing the front of the rack. STEP 3 | Install the appliance in to the equipment rack by sliding the inner-rails in to the outer rack- mount rails unl the appliance stops (about halfway in to the rack).
  • Page 31 Install M-200 or M-600 Appliance in an Equipment Rack appliance in to the rack unl the front of the appliance is flush with the front of the rack. The inner-rail release clips are shown in step 1. STEP 4 | Secure the front of the appliance to the rack by turning the front thumb screws on each rail clockwise unl ght.
  • Page 32 Install M-200 or M-600 Appliance in an Equipment Rack M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 33: Connect Power To An M-200 Or M-600 Appliance

    Connect Power to an M-200 or M-600 Appliance M-200 and M-600 appliances have two AC power supplies (the second power supply is for redundancy). For details on power requirements and power consumpon, see M-200 and M-600 Electrical Specificaons. > Connect AC Power to an M-200 or M-600 Appliance...

  • Page 34: Connect Ac Power To An M-200 Or M-600 Appliance

    Connect Power to an M-200 or M-600 Appliance Connect AC Power to an M-200 or M-600 Appliance The following procedure describes how to connect AC power to an M-200 or M-600 appliance. To avoid injury to yourself or damage to your Palo Alto Networks hardware or the data ®...

  • Page 35: Service An M-200 Or M-600 Appliance

    Service an M-200 or M-600 Appliance The following topics describe how to replace serviceable components on an M-200 or M-600 appliance. For informaon on interpreng the front-panel and back-panel LEDs, see M-200 and M-600 Appliance Overview. > Replace an M-200 or M-600 Drive >...

  • Page 36: Replace An M-200 Or M-600 Drive

    Palo Alto Networks Support. The only difference between replacing an M-200 and M-600 appliance system drive is that the system drive on an M-200 appliance is located on the front panel of the appliance (see M-200 Appliance Front Panel) and the system drive on the M-600 appliance is located on the back panel...
  • Page 37 Service an M-200 or M-600 Appliance STEP 4 | Install the replacement drive in the drive carrier of the failed drive. 1. Place the failed drive next to the replacement drive with the connectors facing the same direcon. 2. Remove the four screws that hold the failed drive in the carrier and remove the drive from the carrier.

  • Page 38: Replace An M-200 Or M-600 Appliance Log Drive

    Replace an M-200 or M-600 Appliance Log Drive The M-200 and M-600 appliance log drives are located on the front of the appliance. Each drive pair (A1 and A2 for example) is in an independent RAID 1 array. This redundant configuraon helps ensure that there is no service interrupon or loss of log data if a disk drive fails.
  • Page 39 Service an M-200 or M-600 Appliance model : ST8000NM0055-1RM size : 7630885 MB status : active sync Disk id A2 Present model : ST8000NM0055-1RM size : 7630885 MB status : failed STEP 2 | Remove the failed drive from the RAID 1 array. In this example, run the following command to remove drive A2 from the array: admin@hostname>...
  • Page 40 Service an M-200 or M-600 Appliance will cause the lever to close part way. When the drive carrier is almost fully inserted, close the lever to seat the drive. 3. Add the replacement drive to the RAID 1 array. In this example, run the following command to add drive A2 to the array: admin@hostname>...
  • Page 41 Service an M-200 or M-600 Appliance will cause the lever to close part way. When the drive carrier is almost fully inserted, close the lever to seat the drive. 3. Copy the data from the exisng drive in the RAID 1 array to the replacement drive. In this example, run the following command to copy the data from drive A1 to drive A2: admin@hostname>...

  • Page 42: Replace An M-200 Or M-600 Appliance Power Supply

    Service an M-200 or M-600 Appliance Replace an M-200 or M-600 Appliance Power Supply M-200 and M-600 appliances have two AC power supplies (the second power supply is for redundancy). If one power supply fails, you can replace it without service interrupon as described in the following procedure.

  • Page 43: M-200 And M-600 Appliance SpecificaOns

    M-200 and M-600 Appliance Specificaons The following topics describe the M-200 and M-600 appliance hardware specificaons. For feature, capacity, and performance informaon, refer to the Panorama Datasheet. ™ > M-200 and M-600 Physical Specificaons > M-200 and M-600 Electrical Specificaons >...
  • Page 44 M-200 and M-600 Appliance Specificaons M-200 and M-600 Physical Specificaons The following table describes M-200 and M-600 appliance physical specificaons. Specificaon Value • M-200 appliance Rack units (U) and dimensions • Rack unit—1U • Dimensions—1.7” H x 29” D x 17.2” W (4.32cm H x 73.67cm D x 43.69cm W)
  • Page 45 M-200 and M-600 Appliance Specificaons M-200 and M-600 Electrical Specificaons The following table describes M-200 and M-600 appliance electrical specificaons. Specificaon Value M-200 and M-600 appliances—Two 750W Power Supplies AC power supplies; the second power supply is for redundancy. M-200 and M-600 appliance—100-240VAC...
  • Page 46 M-200 and M-600 Appliance Specificaons M-200 and M-600 Environmental Specificaons The following table describes M-200 and M-600 appliance environmental specificaons. Specificaon Value M-200 and M-600 appliance—41ºF to 104ºF Operang temperature range (5ºC to 40ºC) Non-operang temperature M-200 and M-600 appliance— -40ºF to 140ºF (-40ºC to 60ºC)

  • Page 47: M-200 And M-600 Miscellaneous SpecificaOns

    M-200 and M-600 Appliance Specificaons M-200 and M-600 Miscellaneous Specificaons The following table describes M-200 and M-600 appliance miscellaneous specificaons. Specificaon Value • M-200 appliance—10 years Mean me between failures (MTBF) • M-600 appliance—8 years M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc.
  • Page 48 M-200 and M-600 Appliance Specificaons M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...

  • Page 49: M-200 And M-600 Appliance Hardware Compliance Statements

    Our products meet standards for product safety and electromagnec compability when used for their intended purpose. To view compliance statements for the M-200 and M-600 appliances, see M-200 and M-600 Compliance...

  • Page 50: M-200 And M-600 Compliance Statements

    M-200 and M-600 Appliance Hardware Compliance Statements M-200 and M-600 Compliance Statements • BSMI EMC Statement—User warning: This is a Class A product. When used in a residenal environment it may cause radio interference. In this case, the user will be required to take adequate measures.
  • Page 51 M-200 and M-600 Appliance Hardware Compliance Statements • VCCI—This secon provides the compliance statement for the Voluntary Control Council for Interference by Informaon Technology Equipment (VCCI), which governs radio frequency emissions in Japan. The following informaon is in accordance to VCCI Class A requirements: Translaon: This is a Class A product.
  • Page 52 M-200 and M-600 Appliance Hardware Compliance Statements M-200 and M-600 Appliance Hardware Reference 2021 Palo Alto Networks, Inc. ©...
