- Page 1 TLMTKIT5 TechGuard Charging Locker ™ Assembly Instructions 010-7102 - Qty 2 010-7115 - Qty 1 Wall Cleat Surface Mount Bracket 030-1796 - Qty 10 010-7103 - Qty 2 #10-32 x 1/2” Serrated Screw Wall Bracket TLMTKIT5 031-10438 Rev 1.0...
-
Page 2: Surface Mounting
Assembly Instructions Surface Mounting 19” (483mm) Charging Locker Unit 19” (483mm) 2.3” (57mm) Unit shown fixed to surface 9” (229mm) 7.8” (198mm) edge for reference 1.4” (34mm) 0.9” (22mm) 010-7115 (1)x TLMTKIT5 031-10438 Rev 1.0... - Page 3 Assembly Instructions Slide unit backward to hook onto bracket. 030-1796 (1)x Do not overtighten. TLMTKIT5 031-10438 Rev 1.0...
-
Page 4: Wall Mounting
Assembly Instructions Wall Mounting Š Consult with a structural engineer or suitable professional prior to mounting. Š Mounting hardware (not provided) and installation method must be suitable with specific wall construction used. Š Only for a single unit of 5-bay. Š Nothing may be placed on top. Š... - Page 5 Assembly Instructions 010-7103 (2)x 030-1796 (8)x TLMTKIT5 031-10438 Rev 1.0...
- Page 6 Assembly Instructions Two Person Side View Assembly Required. Assemble unit to wall cleat. TLMTKIT5 031-10438 Rev 1.0...
- Page 7 Fax: +1-847-678-0852 BRETFORD.COM Bretford, B design, and TechGuard are trademarks or registered marks of Bretford Manufacturing, Inc. or Bretford Manufacturing, Ltd. Patents pending. ©2015 Bretford Manufacturing, Inc. All rights reserved. All other referenced product names and logos are trademarks of their respective owners.
