022-3203 - Qty 4
Upper Leg
4 Leg Voltea Tables
Assembly Instructions
017-1170 - Qty 4
Lower Leg
030-0402 - Qty 5 or 7*
#10-32 x 5/8" Combo Screw
*5 for 36" & 48"W
7 for 60", 72" & 84"W
Table comes with either glides or casters. NOT both.
015-0045 - Qty 4
Threaded Glide
SC1054 - Qty 28
1/4-20 x 3/4" Phillips
Screw
015-0175 - Qty 4
2 1/2" Stem Caster
rake
w/B
030-0396 - Qty 8
3/8-16 x 1/2" Socket
Set Screw
1 of 6
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bretford Edu 2.0
Summary of Contents for Bretford Edu 2.0
- Page 1 4 Leg Voltea Tables Assembly Instructions Table comes with either glides or casters. NOT both. 015-0045 - Qty 4 015-0175 - Qty 4 Threaded Glide 022-3203 - Qty 4 2 1/2” Stem Caster 017-1170 - Qty 4 Upper Leg rake Lower Leg 030-0396 - Qty 8 030-0402 - Qty 5 or 7*...
- Page 2 THIS STEP IS ONLY FOR TABLES 60”W AND LARGER 017-0519 (1)x 030-0354 (2) for 60 & 72 (3) for 84 2 of 6...
- Page 3 022-3203 (1) 4X SC1054 (7) 4x 3 of 6...
- Page 4 Cord bin (1)x 030-0402 (5) for 36 & 48 (7) for 60, 72 & 84 4 of 6...
- Page 5 DEPENDING ON YOUR MODEL INSTALL EITHER CASTERS OR GLIDES 015-0045 (4)X 015-0175 (4)X 017-1170 017-1170 (4)X (4)X 5 of 6...
- Page 6 HEIGHT ADJUSTMENT HOLES 030-0396 (2) 4X Part # 031-9204 6 of 6 05.25.12 CZ...
