35XTC17 35XTC14
35XTC18 35XTC26
Adjustable Work Center with
CPU Holder and Casters
(30" DEPTH ONLY)
Assembly Instructions
35XTC17
36" wide one grommet hole
35XTC14
42" wide one grommet hole
Parts List
Qty.
Part No. Description
1
SA2339
Table Top (36")
SA2340
Table Top (42")
SA2341
Table Top (48")
SA2342
Table Top (72")
2
022-2036
Leg Assembly - Lower
1
022-1589
Leg Assembly - Upper Right
1
022-1590
Leg Assembly - Upper Left
1
010-2321
Modesty Panel (36")
010-3080
Modesty Panel (42")
010-2324
Modesty Panel (48")
010-2706
Modesty Panel (72")
1
010-2322
Cord Bin (36")
010-3081
Cord Bin (42")
010-2325
Cord Bin (48")
010-3075
Cord Bin (72")
2
010-3344
CPU Side Holder-w/hole
(1 required on 35XTC14,
35XTC17 & 35XTC18)
010-4981
CPU Holder w/Hole for MT Models
2
010-3343
CPU Side Holder-w/slot
(1 required on 35XTC14,
35XTC17 & 35XTC18)
010-4980
CPU Holder w/Slot for MT Models
Tools Required
Phillips Screwdriver
Rubber Mallet
Allen Wrench (provided)
7/16" Open/Box End Wrench
Electric Drill
1/8" Dia. Drill Bit
35XTC18
48" wide
Hardware List
Qty.
Ref.
Part No. Description
12
AA
030-0402
12
BB
030-0240
4
CC
030-0396
4
DD
030-0325
6
EE
030-0168
2
FF
030-0433
2
HH
030-0465
2
JJ1
015-0002
2
JJ2
015-0003
8
KK
030-0305
8
LL
030-0453
2
MM
030-0272
2
NN
030-0306
2
PP
030-0256
1
030-0397
35XTC26 72" wide,
two grommet holes,
two CPU holders
two grommet holes
#10-32 x 5/8" Combo Screw
Washer, External Tooth
3/8-16 x 1/2" Set Screw
1/4-20 x 1/2" Combo Screw
#8 x 1/2" Wood Screw
#10-32 x 1/2" Knurled Knob Screw
Retaining Washer - Nylon
4" Caster without Lock
4" Caster with Lock
Washer, Flat (6 required on 35XTC14,
35XTC17 & 35XTC18)
#12 x 3/4" Phillips Truss Head Screw
(4 reqiured on 35XTC14, 35XTC17 &
35XTC18)
1/4-20 x 1/2" Carriage Bolt (1 reqiured
on 35XTC14, 35XTC17 & 35XTC18)
Washer, Flat (1 reqiured on 35XTC14,
35XTC17 & 35XTC18)
1/4-20 Flanged Nut (1 required on
35XTC14, 35XTC17 & 35XTC18)
Allen Wrench
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bretford 35XTC17
Summary of Contents for Bretford 35XTC17
-
Page 1: Parts List
35XTC17 & 35XTC18) 010-2322 Cord Bin (36") 030-0453 #12 x 3/4" Phillips Truss Head Screw 010-3081 Cord Bin (42") (4 reqiured on 35XTC14, 35XTC17 & 010-2325 Cord Bin (48") 35XTC18) 010-3075 Cord Bin (72") 030-0272 1/4-20 x 1/2" Carriage Bolt (1 reqiured... - Page 2 modesty panel mounting holes FRONT Step 1 Lay the table top on a carpeted surface with holes facing up. Position the legs onto the table top with the modesty panel mounting holes facing inward as shown. Loosely attach legs with screws (AA) and washers (BB).
- Page 3 See Detail 'A' Detail 'A' Step 3 Slide the modesty panel between the two legs. Align the modesty panel mounting holes with the leg mounting holes. Loosely install screws (DD). Secure the modesty panel to the table top with screws (EE) as shown in Detail 'A'.
- Page 4 square hole NOTE: The table is predrilled so the first cpu bracket can mount on the left or right side of your table Step 5 Attach the CPU bracket with the square hole located on the bottom flange first. Install with washers (KK) and screws (LL) as shown.
- Page 5 Install casters (JJ1) and (JJ2) into leg bottom as shown (a rubber mallet may be required to fully insert the caster stem into leg). Carefully turn over the table and place into position and lock the casters. Bretford Bretford Manufacturin Ltd. 11000 Seymour Avenue 2 E t o n g a t e...
