Zena
Installation Guide
For Model:
ZE56
net weight of fan: 19.80 lb (9.00 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 5
Warranty. pg. 8
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zena ZE56 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade Zena ZE56

Summary of Contents for Craftmade Zena ZE56

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Zena Installation Guide For Model: ZE56 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the inches 7 feet (76cm) blades a clearance of 7ft. (2.13m) from the (2.13m) floor and 30in. (76cm) from any wall or obstruction. 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly set screw stop pin Remove hanging ball from downrod by loosening set screw on hanging ball. Lower hanging ball and remove hanging ball stop pin and then slide hanging ball off of the downrod. [Refer to diagram 1.] diagram 1 Loosen yoke set screws and nuts at top of motor housing.

  • Page 6: Wiring

    5. Fan Assembly. (cont.) wood ceiling joist With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. safety cable loop Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.

  • Page 7: Canopy Assembly

    7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and hanging bracket remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in screw canopy over loosened screw in hanging bracket and push up.

  • Page 8: Switch Housing Assembly

    motor housing 9. Switch Housing Assembly. Remove 3 screws from outer edge of switch housing plate (save screws for later use). fitter plate Remove 1 screw from fitter plate on underside of motor and partially loosen the other 2 screws. Align slotted holes in center of switch housing plate with loosened screws in fitter plate, allowing switch housing plate...

  • Page 9: Troubleshooting

    Problem: Fan fails to operate. Service at 1-800-486-4892 to arrange for return of fan. Solutions: Return fan, shipping prepaid, to Craftmade. We will repair 1. Check wall switch to fan. or ship you a replacement fan, and we will pay the return 2.
