Waterdrop WD-TSB-10 Installation Instructions

Triple Stage Undersink Water Filtration System
WD-TSB-10 system | Installation Instructions
WARNING Please read it carefully before installation.
Filter head
Stainless faucet
Quick-connect fitting
Specifications
Operating temperature 2-38℃/35-100℉
Working pressure 10-125psi (0.7-8.6bar)
Flow rate 1gpm
WD-10PP: up to 6 months
Filter capacity WD-10GC: up to 8-12 months
WD-10CT: up to 12-18 months
Feed water requirement Municipal tap water
Note: The service life mentioned above is subject to chlorine reduction. Actual result varies according
to the local water quality.

Precautions

• Do not use it with water that's microbiologically unsafe or of unknown quality without adequate disinfection.
• For use only with cold water.
• Do not freeze the lter, as this can cause cracking and water leakage.
• Do not allow children under 3 years old to have access to small parts during installation of this product.
• This installation must comply with all applicable state and local regulations.
• Turn o the water supply while replacing the lter.
Installation of the filter system
Tips: How to use the quick-connect?
To connect: There is an existing mark at the end of the tubing for you to con rm if the tubing is fully
inserted into the tting. (Figure 1)
To disconnect: Use your thumb and index nger to press down on the lock sleeve. Use your other hand to
pull out the hose from the tting. (Figure 2)
Note: Please do not pull out the tubing directly, or else it will damage the tting and cause leakage.
Figure 1
1/4" tubing
3/8"-1/2" converter
Feed water adapter
3/8"-1/2" converter
Step 1: Fix the filter head and the filter
Teflon tape
1. Paste the assistant label to nish drilling.
Note: Mount the water lter at least 2 inches higher
than the ground for easier lter change.
2. Install the screw and reserve enough space to hang the lter.
3. Hang the lter system on the screw.

Step 2: Connect the water supply (cold water only)

1. Shut o the water supply and remove the faucet hose.
2. Connect the feed water adapter and ensure that the rubber O-ring is loaded.
• If the angle valve outlet is 3/8", connect it to the water supply and faucet hose directly. (Figure 3)
• If the angle valve outlet is 1/2", you need to remove the above two ttings before connection. (Figure 4)
3. Connect one end of the 1/4" PE tubing to the inlet of the lter head. Until you reach the mark on the
tubing.
Figure 3
Figure 2
Mark for full insert
Figure 4
3/8" Cold water valve 1/2" Cold water valve
Press
Pull
Press
