- Page 1 ASSEMBLY INSTRUCTIONS Description : 32 X 12 X 48 HIGH BOOK CASE RTA Item No. : SH-3224A ITEM NO. : SH-3224A Printed in Vietnam REVISED APR 06, 2016 - 1 -...
-
Page 2: Before Assembly
Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO. : SH-3224A Printed in Vietnam REVISED APR 06, 2016 - 2 -... -
Page 3: Parts List
(M4 x 110mm) Shelf support Short screw bracket M3.5 x 15mm Long screw Steel band (M4 x 30mm) Pan head Flat washer screw (6.5 x19mm) (M4 x 20mm) ITEM NO. : SH-3224A Printed in Vietnam REVISED APR 06, 2016 - 3 -... - Page 4 Remove the paper strip and attach sticky side of connecters (G) to back of the unit. Then attach connecters (G) to the top (A) and bottom panel (C) and shelf panel (D) with pan head screws (9). Tighten with a screwdriver. ITEM NO. : SH-3224A Printed in Vietnam REVISED APR 06, 2016...
- Page 5 Attach steel bands (8) to the unit with screws (6). Then attach the steel band to a wall with screws (7) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO. : SH-3224A Printed in Vietnam...
