H-7822, H-9129
SLED BASE CHAIR
WITH ARMRESTS
TOOL NEEDED
Allen Wrench
(included)
Back Cushion x 1
Leg with Armrest x 2
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS
Seat Cushion x 1
ASSEMBLY
4
Hardware Kit
4
Screw x 4
5/16 x 7/8"
6
Screw x 2
5/16 x 1⁄"
1. Align leg mounting plates with holes on bottom of
seat cushion. Use two 5/16 x 7/8" screws (4) to loosely
secure. Repeat on opposite side. (See Figure 1)
NOTE: Do not tighten screws until assembly is
complete.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
5
Screw x 2
5/16 x 1"
7
Plastic Cap x 4
0721 IH-7822
Advertisement
Related Manuals for U-Line H-7822
Summary of Contents for U-Line H-7822
- Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-7822, H-9129 1-800-295-5510 uline.com SLED BASE CHAIR WITH ARMRESTS TOOL NEEDED Allen Wrench (included) PARTS Hardware Kit Back Cushion x 1 Seat Cushion x 1 Screw x 2 Screw x 4 5/16 x 1"...
- Page 2 ASSEMBLY CONTINUED 2. Align back cushion with mounting holes. Use one Figure 2 5/16 x 1" screw (5) in top hole and one 5/16 x 1⁄" screw (6) in bottom hole to loosely secure. Repeat on opposite side. (See Figure 2) NOTE: Use Allen wrench to tighten all screws.
-
Page 3: Herramienta Necesaria
H-7822, H-9129 800-295-5510 uline.mx SILLA CON ARMAZÓN TIPO TRINEO CON DESCANSABRAZOS HERRAMIENTA NECESARIA Llave Allen (incluida) PARTES Kit de Tornillería 2 Tornillos 1 Respaldo Acojinado 1 Asiento Acojinado 4 Tornillos 5/16 x 1" 5/16 x 7/8" 2 Patas con 2 Tornillos... - Page 4 CONTINUACIÓN DEL ENSAMBLE 2. Alinee el respaldo acojinado con los orificios de Diagrama 2 instalación. Utilice un tornillo de 5/16 x 1" (5) en el orificio superior y uno de 5/16 x 1¼" (6) en el inferior para asegurarlos sin apretar. Repita en el lado opuesto.
-
Page 5: Montage
H-7822, H-9129 1-800-295-5510 uline.ca CHAISE À BASE TRAÎNEAU EN VINYLE AVEC ACCOUDOIRS OUTIL REQUIS Clé Allen (inclus) PIÈCES Matériel d'installation Coussin de dossier x 1 Coussin de siège x 1 Vis x 2 Vis x 4 5/16 x 1 po... - Page 6 MONTAGE SUITE 2. Alignez le dossier sur les trous de fixation. Utilisez une Figure 2 vis de 5/16 x 1 po (5) dans le trou supérieur et une vis de 5/16 x 1 ¼ po (6) dans le trou inférieur et fixez sans serrer.
