Para Español, vea páginas 4-6. Pour le français, consulter les pages 7-9. H-7628 1-800-295-5510 uline.com DOWNTOWN MESH CHAIR TOOL INCLUDED Allen Wrench PARTS Hardware Kit Seat Cushion x 1 5-Star Base x 1 Caster x 5 Screw x 4 Screw x 6 1/4 x 1⁄"...
Page 2
ASSEMBLY CONTINUED 2. Align armrest with holes on bottom of seat cushion. Figure 2 Use three 1/4 x 1/" screws (8) with three washers (11) to attach. Repeat on opposite side. (See Figure 2) NOTE: Use Allen wrench to tightly secure all screws.
ASSEMBLY CONTINUED 5. Slowly lower chair assembly onto the gas lift. Press Figure 5 down on seat cushion to secure. (See Figure 5) CHAIR ADJUSTMENTS 1. Seat Height Adjustment – To raise seat height, lift lever up with little to no weight on the seat. To lower seat height, lift lever up while sitting.
Page 4
H-7628 800-295-5510 uline.mx SILLA DE MALLA URBANA HERRAMIENTA INCLUIDA Llave Allen PARTES Kit de Tornillería 4 Tornillos 6 Tornillos 1 Asiento 1 Base Estrella 5 Ruedas 1/4 x 1⁄" 1/4 x 1⁄" 1 Respaldo 3 Tornillos 6 Rondanas 1 Pistón de Gas...
Page 5
CONTINUACIÓN DE ENSAMBLE 2. Alinee el descansabrazos con los orificios debajo Diagrama 2 del asiento. Use tres tornillos 1/4 x 1½" (8) con tres rondanas (11) para fijar. Repita en el lado opuesto. (Vea Diagrama 2) NOTA: Use la llave Allen para fijar bien todos los tornillos.
Page 6
CONTINUACIÓN DE ENSAMBLE 5. Baje lentamente el ensamble de la silla sobre el Diagrama 5 pistón de gas. Presione el asiento hacia abajo para asegurarlo. (Vea Diagrama 5) AJUSTES DE LA SILLA 1. Ajuste de la Altura del Asiento – Para aumentar la altura del asiento, levante la palanca sin o con poco peso en el asiento.
H-7628 1-800-295-5510 uline.ca DOWNTOWN – CHAISE EN MAILLE OUTIL INCLUS Clé Allen PIÈCES Matériel d'installation Vis x 4 Siège x 1 Base à 5 branches x 1 Roulette x 5 Vis x 6 1/4 x 1 ¼ po 1/4 x 1 ½ po...
Page 8
MONTAGE SUITE 2. Alignez l'accoudoir avec les trous situés au bas du Figure 2 siège. Fixez avec trois vis de 1/4 x 1 ½ po (8) et trois rondelles (11). Répétez la procédure sur le côté opposé. (Voir Figure 2) REMARQUE : Utilisez la clé...
Page 9
MONTAGE SUITE 5. Abaissez lentement la chaise sur le vérin Figure 5 pneumatique. Appuyez sur le siège pour le fixer. (Voir Figure 5) RÉGLAGES DE LA CHAISE 1. Réglage de la hauteur du siège – Pour élever la hauteur du siège, soulevez le levier avec peu ou sans poids sur le siège.
