© 2009, Videolarm, Inc. All Rights Reserved
FDW8CF2
Fusion Dome (Outdoor/Indoor Housing with Wall Mount)
Installation and Operation Instructions for the following models:
FDW8CF2
8" Outdoor dome hsg w/wall mount, clear dome, w/24Vac input,
heater/ blower, (1) fixed camera bracket, MCL8.5"
FDP8CF2
8" Outdoor dome hsg w/pendant mount, clear dome, w/24Vac input,
heater/ blower, (1) fixed camera bracket, MCL8.5"
FDP8CF2
8" Indoor dome hsg w/wall mount, tinted dome, plus (1) fixed camera
bracket, MCL8.5"
IFDP8CF
8" Indoor dome hsg w/pendant mount, tinted dome, plus (1) fixed camera
bracket, MCL8.5"
Before attempting to connect or operate this product,
please read these instructions completely.
© 2009, Videolarm, Inc. All Rights Reserved
www.videolarm.com
CERTIFIED
81-IN5417
01-29-2009
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Moog Videolarm FDW8CF2
Summary of Contents for Moog Videolarm FDW8CF2
- Page 1 © 2009, Videolarm, Inc. All Rights Reserved © 2009, Videolarm, Inc. All Rights Reserved FDW8CF2 Fusion Dome (Outdoor/Indoor Housing with Wall Mount) www.videolarm.com Installation and Operation Instructions for the following models: FDW8CF2 8” Outdoor dome hsg w/wall mount, clear dome, w/24Vac input, heater/ blower, (1) fixed camera bracket, MCL8.5”...
- Page 2 IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. 1 Read Instructions - All the safety and operating Keep these instructions. instructions should be read before the unit is CAUTION CAUTION operated. Heed all warnings RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK 2 Retain Instructions - The safety and operating DO NOT OPEN...
- Page 3 LIMITEDWARRANTY FOR VIDEOLARM INC. PRODUCTS VIDEOLARMINC. warrantsthis Productto be free from defectsin materialor workmanship,as follows: PRODUCTCATEGORY PARTS LABOR All Enclosures and Electronics Five (5) Years Five (5) Years Pan/Tilts Three (3) Years **6 months if used in autoscan Three (3) Years **6 months if used in autoscan /tour operation /tour operation Poles/PoleEvators...
-
Page 4: Electrical Specifications
Electrical Specifications Contents of Box FDW8CF2 Power 24VAC Class 2 Only 24 VAC 26 Watts Accessories: Heater: 25 Watts, Blower: 1 Watt Camera Power: 32 Watts Max Tools Required: .100” Flat Head Screwdriver Phillips Head Screwdriver English 24 VAC 26 vatios... - Page 5 WALL MOUNTING Securely mount unit to wall or to appropriate If using conduit connect, connect to adapter bracket. incoming conduit fitting. • Monte con seguridad la unidad a la pared o al • Si usa el conducto conecte, conecte con la guar- soporte apropiado del adaptador.
- Page 6 FOR PENDENT/ WALL MOUNTING Wrap Teflon tape around the pipe threads Securely mount bracket to wall. Pull wiring to ensure a tight seal. through bracket and position grommet as shown. • Con seguridad soporte del montaje a emparedar. Tire del cableado •...
- Page 7 Loop the lanyard over the set screw to Make the appropriate wiring connections temporarily hold housing. from the dome to the gooseneck. • Coloque el acollador sobre el tornillo de presión para • Haga las conexiones apropiadas del cableado de la bóveda celebrar temporalmente la cubierta.
- Page 8 Loosen the thumb screws to adjust the Bolt camera to camera bracket as shown. cameras height and tilt angle. • Cámara fotográfica del perno al soporte de la cámara • Afloje los tornillos de pulgar para ajustar la altura de las fotográfica según lo demostrado.
-
Page 9: Replacement Parts List
• Prenda abaixo a abóbada com uma chave de fenda Phillips. • Asciughi la cupola. • Fissisi giù la cupola con un cacciavite "phillips". Replacement Parts List Item Part Comments FDW8CF2 Number Number FDP8CF2 Plastic Housing Top RPFD030 Housing Gasket RP96GK2612 ... -
Page 10: Product Registration/Warranty
Product Registration/Warranty Thank you for choosing Videolarm. We value your patronage and are solely committed to providing you with only the highest quality products available with unmatched customer service levels that are second-to-none in the security industry. Should a problem arise, rest assure that Videolarm stands behind its products by offering some of the most impressive warranty plans available: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on all camera systems (SView, QView, Warriors), and InfraRed Illuminators.
