Appendix F. Pin Lists; Table F-1. Db25 Interface Cable Pin List; Table F-2. Db9 Interface Cable Pin List - Magtek MICR Plus Technical Reference Manual

The pin list for the DB25 Interface Cable is shown in Table F-1, and the pin list for the DB9
Interface Cable is shown in Table F-2.
PIN SIGNAL
(Host as Reference)
2 TXD
3 RXD
4 RTS
5 CTS
6 DSR
8 DCD
7 GND
20 DTR
PIN SIGNAL
(Host as Reference)
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS

APPENDIX F. PIN LISTS

Table F-1. DB25 Interface Cable Pin List

Transmitted Data. Transmits data from the Host to the MICR Plus.
Received Data. Receives data from the MICR Plus to the Host.
Request to Send. Sends a signal to the MICR Plus to indicate that
the Host is ready to receive data.
Clear to Send. Receives a signal from the MICR Plus to indicate
that the MICR Plus is ready to send data.
Data Set Ready. Receives a signal from the MICR Plus to indicate
that the MICR Plus is active, i.e., power is on.
Ground
Data Terminal Ready. Transmits a signal to the MICR Plus to
indicate that the Host is active, i.e., power is on.

Table F-2. DB9 Interface Cable Pin List

Received Data. Receives data from the MICR Plus to the Host.
Transmitted Data. Transmits data from the Host to the MICR Plus.
Data Terminal Ready. Transmits a signal to the MICR Plus to
indicate that the Host is active, i.e., power is on.
Ground
Data Set Ready. Receives a signal from the Host to indicate that the
MICR Plus is active, i.e., power is on.
Request to Send. Sends a signal to the MICR Plus to indicate that
the Host is ready to receive data.
Clear to Send. Receives a signal from the MICR Plus to indicate that
the MICR Plus is ready to send data.
