APPENDIX C. TROUBLESHOOTING GUIDE

REQUIREMENTS

• Personal Computer.
• RS-232 cable, P/N 22617504 or 22617506.
• AC adapter, P/N 64300050.
• SET-MICR program, P/N 22000020 (Rev P or higher).
• Sample checks, P/N 96530005.
• A small bottle of compressed air.
• A cleaning card, P/N 96700006.

SET-UP

1. Plug the 9-pin din connector of the RS-232 cable into the MICR Plus.
2. Plug the DB25 or DB9 connector of the RS-232 cable into the PC.
3. Power on the MICR Plus.
4. Run the SET-MICR program on the PC.
5. Press <F9> to establish communication between the PC and the MICR Plus.

PROCEDURE

Start trouble-shooting procedure at Step 00.
00 Check LED
Check the status of the LED indicator:
◊ off, continue to step 01.
◊ green, continue to step 02.
◊ blinking red, continue to step 11.
◊ blinking green, continue to step 17.
◊ blinking red/green, continue to 13.
◊ red or orange, continue to step 18.
