Magtek MICR Plus Technical Reference Manual page 32

MICR PLUS, RS-232
Fmt 01xx: Parsed Text Format
FC0100
FC0101
Field Labels - TR-transit, AC-account #, CK-check #, AM-amount, TP-tpc,
Example:
Fmt 02xx: Parsed Text Format with Error Labels
FC0200
FC0201
Error Labels - PE-parsed error, NE-no error, TR-transit error,
Examples:
Fmt 03xx: [acct #]
• [acct #]: - maximum of xx characters; when xx=00 all characters are sent
- keep spaces and dashes
Fmt 04xx: [acct #]
• [acct #]: - maximum of xx characters; when xx=00 all characters are sent
- remove spaces and dashes
Fmt 05xx: [acct #]
• [acct #]: - maximum of xx characters; when xx=00 all characters are sent
- replace spaces and dashes with zeros
Fmt 06xx: [acct #]
• [acct #]: - always xx characters, zero filled;
- replace spaces and dashes with zeros
Fmt 07xx: [acct #]
• [acct #]: - always xx characters, zero filled;
- remove spaces and dashes
Fmt 08xx: [transit] [acct #]
• [transit]: - all characters in the field
- keep dashes
• [acct #]: - maximum of xx characters; when xx=00 all characters are sent
- remove spaces and dashes
24
- Parsed text with dashes
- Parsed text, replace dashes with "d"
EP-epc
- PTTR444455556;AC 999-222-3;CK11045
- Parsed text with dashes
- Parsed text, replace dashes with "d"
CK-chk # error, TC-transit check digit error,
AM-amount error, OU-on us/account# error, TP-tpc error
- PTTR444455556;AC999-222-3;CK11045/PENE
- PTTR111?11111;AC123456/PETR ("?" = unreadable character)
when xx=00 all characters are sent
when xx=00 all characters are sent
