DEMO MANUAL DC2376A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 3 C1, C6, C7
2 9 C2, C3, C8, C9, C11 TO C15
3 1 C5
4 2 D1, D2
5 23 E1 TO E17, E22, E24, E28 TO E31
6 4 JP1, JP2, JP3, JP4
7 1 J1
8 1 LED1
9 1 Q1
10 0 R1, R2, R10
11 8 R3 TO R9, R12
12 1 R11
13 1 U2
14 1 U3
DC2376A-A Required Circuit Components
2 1 U1
DC2376A-B Required Circuit Components
2 1 U1
6
PART DESCRIPTION
CAP, X5R, 10µF 25V, 10%, 1206
CAP, X7R, 0.1µF 25V, 10%, 0603
CAP, X7R, 0.01µF 25V, 10%, 0603
DIODE, SCHOTTKY DUAL 30V, SOT23-3
TURRET, TESTPOINT 0.064"
HEADER, 2MM SINGLE STR 3POS
CONN, HEADER 14POS 2MM VERT GOLD
LED, RED, LED-ROHM-SML-010VT
MOSFET, N-CH 60V 300MA SOT-23
RES, 0603
RES, CHIP, 4.99k, 1/10W, 1% 0603
RES, CHIP, 1k, 1/10W, 1% 0603
IC, LT1761ES5-5, SOT23-5
IC, 24LC025-I/ST, TSSOP8
IC, 16-BIT, QFN32UH-5X5
IC, 12-BIT, QFN32UH-5X5
MANUFACTURER/PART NUMBER
MURATA, GRM31CR61E106KA12L
MURATA, GRM188R71E104KA01D
MURATA, GRM188R71E103KA01D
DIODES INC, BAT54C-7-F
MILL-MAX, 2308-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
MOLEX, 87831-1420
ROHM, SML-010VTT86L
VISHAY SILICONIX, 2N7002K-T1-E3
OPT
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW06031K00FKEA
LINEAR TECHNOLOGY, LT1761ES5-5#PBF
MICROCHIP, 24LC025-I/ST
LINEAR TECHNOLOGY, LTC2664IUH-16
LINEAR TECHNOLOGY, LTC2664IUH-12
