ADJUSTABLE FEATURES
SX TRANSISTOR CONTROLS
(Push CONT 8)
This function is used to reduce the ripple in field current
due to the interaction between motor field design and the
digital field current regulation circuit. The value for this
function should be set to 0.
Important Note: The function is used to optimize motor and
control performance and this setting will be determined by
GE and OEM engineers at the time of vehicle development.
This setting must not be changed by field personnel without
the permission of the OEM.
FUNCTION 24 FIELD WEAKENING START (or MOTOR
KNEE POINT)
This function allows for setting the armature current at
which minimum field current will be achieved.
Range
Setting
Resolution
Example:
Important Note: The function is used to optimize motor and
control performance and this setting will be determined by
GE and OEM engineers at the time of vehicle development.
This setting must not be changed by field personnel without
the permission of the OEM.
FUNCTION 25 NOT USED
Value should be set at zero.
FUNCTION 26 RATIO OF FIELD TO ARMATURE AMPS
This function sets the ratio between armature and field
current when transitioning from minimum field to maximum
field current. The setting represents the quantity of field
current changed for each 1 amp of armature current
changed.
0 to 255Amps
0 to 255
1.0 per set unit
Setting of 26 = 26 amps.
Max Resolution
Change Set Per unit value
.18 0 to 255 0.00072 amps
FUNCTION 27 HOUR METER MINUTES
This function adjusts the number of 30 second intervals
registering in the hour meter. This function is typically not
set by an OEM, it is usually only read from the register.
Range 0 to 60 minutes
Resolution 0.5 minutes per set unit
Setting 0 to 120
Example Setting of 60 = 60 x 0.5 = 30 minutes
FUNCTION 28 STORED STATUS CODE COUNT
POINTER
This register contains the location of the last stored status
code recorded of the 16 stored status codes. These stored
status codes have caused a PMT controller shutdown
and/or disruption of normal vehicle operation.
FUNCTION 29 HOUR METER TENS AND UNITS
HOURS SET
This function allows for the adjustment of the tens and
units hours of the hour meter.
Range
Set
Example
FUNCTION 30 HOUR METER THOUSANDS
AND HUNDREDS HOURS SET
This function allows for the adjustment of the thousands
and hundreds hours of the hour meter.
Range
Set
Example
Page 33
Example
If set at 100
0.072 amps
0 to 99
0 to 99
9999 Hours
0 to 99
0 to 99
9999 Hours
