INSTALLATION AND OPERATION
SX TRANSISTOR CONTROL
TRACTION
STATUS CODE
-65 The line coil current is too high
during the run mode
MEMORY RECALL CORRECTIVE ACTIONS
YES
SYMPTOM
Control will not operate.
Circuits valid
for
POSSIBLE CAUSE
Traction
Controller
Shorted line contactor coil
Short between wires
connected to line coil (wires
#10 and 24)
Insure that all inductive loads
are suppressed.
Incorrect line contactor coil.
Defective control.
•
TRACTION
DESCRIPTION OF STATUS
STATUS CODE
The field current exceeds the current limit
-66
of the field transistor.
MEMORY RECALL
YES
SYMPTOM
Control will not operate or is sluggish on
Circuits valid
start up. Line contactor opens.
for
Traction
POSSIBLE CAUSES
Controller
• Shorted field F1 to F2
• F1 or F2 terminals shorted to battery
positive (B+)
Confirm that all inductive
•
loads/accessories are suppressed.
Motor armature or field shorted to
•
frame.
Defective control.
Replace controller unit.
•
DESCRIPTION OF
STATUS
Replace controller unit.
CORRECTIVE ACTIONS
CAUSE OF STATUS INDICATION
This status code will be displayed when the current limit in
the line coil is exceeded during the run mode. The line
contactor will drop out and the key switch will have to be
recycled to reset the control.
TROUBLE-SHOOTING DIAGRAM
+72V
+72V
L
P1
P17 P2
P12
+72V
72V
NEG
CAUSE OF STATUS INDICATION
This status code will be displayed when the field
transistor exceeds its current limit. The line
contactor will drop out and the key switch will have
to be recycled to restart the control.
TROUBLE-SHOOTING DIAGRAM
+72V
L
P1
P17
P12
72V
NEG
+72V
+72V +72V +72V
P6
P4 P5
P21
P9 P7 P8
P3 P22 P23
P20
RS232
ACC POT
TACHOMETER
+72V +72V
+72V
+72V +72V
P2 P6
P4
P21
P9 P7 P8
P3
P22 P23 P20
RS232
ACC POT
+72V
Page 27
+72V
P10
P15 P14 P16
+72V
P5 P10
P15 P14 P16
TACHOMETER
Updated Sept 2019
