INSTALLATION AND OPERATION
SX TRANSISTOR CONTROL
TRACTION DESCRIPTION OF STATUS
STATUS CODE
Accelerator voltage input is too high on
-08
power up after initial key switch
closure.
MEMORY RECALL
NO
SYMPTOM
Control will not operate
Circuits valid
for
Traction
POSSIBLE CAUSE
Accelerator input is mis-adjusted or
Controller
defective.
• Input voltage at P7 should be less than
0.9 volts. Adjust or replace accelerator
unit to insure that the voltage at P7 is less
than 0.9 volts before depressing pedal.
Open circuit at P8 or open potentiometer
wiper at P7 – verify continuity of wiring at
both points.
TRACTION
STATUS CODE
Both the forward and reverse switches or
-09
the turf and reverse switches are closed at
the same time.
MEMORY RECALL
NO
SYMPTOM
Control will not operate.
Circuits valid
for
POSSIBLE CAUSE
Traction
Forward or reverse or turf switch welded closed
or mis-adjusted to be held closed.
Controller
• Replace or adjust directional switches to insure
that they are open when switch is returned to
neutral or off.
Short circuit between battery positive and P4,P5
and/or P6.
•
check wire for short circuit to positive side of
directional switch
Defective control.
• Disconnect wires and measure voltage at P4,
P6 and P5. Voltage should be less than 50%
of battery volts, if not, replace control.
CORRECTIVE ACTIONS
DESCRIPTION OF STATUS
CORRECTIVE ACTIONS
Disconnect wires from P4, P6 and P5 and
CAUSE OF STATUS INDICATION
This status code will be displayed when the
accelerator input voltage at P7 >0.9V when the
battery plug or key switch is opened and closed.
TROUBLE-SHOOTING DIAGRAM
+72V
+72V +72V
L
P1
P17 P2
P12 P3 P22
+72V
72V
NEG
CAUSE OF STATUS INDICATION
This status code will be displayed when P4 and
P5 or P6 and P5 are greater than 50% of battery
volts.
TROUBLE-SHOOTING DIAGRAM
+72V
+72V
L
P1
P17 P2
P3
P12
+72V
72V
NEG
Page 17
+72V +72V
+72V +72V
P6 P4 P5
P21
P9 P7 P8
P15 P14 P16
P23
P20
RS232
ACC POT
TACHOMETER
+72V
+72V +72V +72V
P6
P4 P5
P21
P9 P7 P8
P15 P14 P16
P22 P23 P20
RS232
ACC POT
TACHOMETER
Updated Sept 2019
