User Manual for your
UBETFD605BK
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UBETFD605BK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Culina UBETFD605BK

Summary of Contents for Culina UBETFD605BK

  • Page 1 User Manual for your UBETFD605BK NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for...
  • Page 2 Warning 1、WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. 2、Children less than 8 years of age shall be kept away unless continuously supervised. 3、the appliance must not be installed behind a decorative door in order to avoid overheating.
  • Page 3 2、Copiii mai mici de 8 ani pot sta în preajma plitei doar dacă sunt permanent supravegheați. 3、Dispozitivul nu trebuie instalat în spatele unei uși decorative, pentru a evita supraîncălzirea. 1、ADVERTENCIA: El aparato y las piezas accesibles se calientan durante el uso.

  • Page 4: Table Of Contents

    Contents Environmental note Important safety information 4 - 6 Specifications 7 - 9 Product and aperture dimensions Product specifications Standard accessories Electrical details Cooling fan Control panel Oven programmer/timer display Setting and using the oven programmer/timer 10-14 Selecting manual operation mode Setting clock (the time of day) The oven timer Before first use...

  • Page 5: Environmental Note

    Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 6: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Customer Care Department.
  • Page 7 o This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Child Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to...
  • Page 8 o IMPORTANT: The appliance must be disconnected from the mains before following the cleaning procedure. Installation This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o The manufacturer declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.

  • Page 9: Specifications

    Specifications Product Dimensions Aperture Dimensions Height: 595 mm 600 mm Width: 595 mm 560 mm Depth: 530 mm 560 mm (min) Product specifications o 4 oven functions o Energy efficiency class: A o Oven net/gross capacity: 58/65 liters o LED fully programmable timer o Cooling fan o Thermostatically controlled grill o Double-glazed removable door...

  • Page 10: Standard Accessories

    Standard accessories Accessory Name Picture Quantity Baking tray Grill Each 1 Handle Screws(ST4x35) Electrical details Rated Voltage: 220-240 Vac, 50/60 Hz Supply Connection: 13A (double pole switched fused outlet with 3mm contact gap) Rated max power : 2.20 kW Mains Supply Lead: 3 x 1.5mm²...

  • Page 11: Control Panel

    Control Panel 1) Oven function selector knob 2) Thermostat control knob 3) Minute minder button 4) Duration button 5) End cook button 6) Manual operation button 7) Minus button 8) Plus button 9) LED display A) Power indicator light B) Oven operating light Oven programmer/timer display 10) Auto function symbol 11) Minute minder symbol...

  • Page 12: Setting And Using The Oven Programmer/Timer

    Setting and using the oven programmer/timer Selecting manual operation mode After your appliance is connected to your mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature,you must set the appliance into manual operation mode.

  • Page 13: Setting The Minute Minder Function

    o You should leave the oven on maximum setting for 30 – 40 minutes. o After the oven cavity has cooled, it should then be cleaned with warm soapy water, using either a sponge or soft cloth. No abrasive cleaners should be used. o Outer parts of the oven should be cleaned with warm soapy water, using either a sponge or soft cloth.

  • Page 14: Setting The End Cook Function

    o Use the thermostat control knob (2) to set the temperature that you require. The manual operation symbol (12) will appear on the display. o Use the oven function selector knob (1) to select the mode of cooking that you require. o It is then possible to set the duration of the cooking time that you require.

  • Page 15: Setting The Start And End Time Function

    o Press the end cook button (5) and the display will show a value of 00:00. Set the time of day that you wish the oven to stop cooking at by using the minus (7) and plus (8) buttons. The timer will calculate how long the cooking time will be, based on the time of day that you have selected and show it on the display.
  • Page 16 the minus (7) and plus (8) buttons. The word AUTO will appear on the timer display. o Immediately press the end cook button (5) and the timer display will show the value 00:00. Set the time of day that you want the oven to switch off at, using the minus and plus buttons.

  • Page 17: Selecting A Cooking Function And Temperature

    Selecting a cooking function and temperature IMPORTANT: Make sure that you have sent your oven into manual operation mode before selecting an oven function and temperature. Selecting an oven function The oven function selector knob should be used to select the particular mode of cooking that you require.

  • Page 18: Thermostat Control Knob

    Thermostat control knob o The oven thermostat control knob sets required temperature of the oven. It is possible regulate temperature within a range of 50 - 250°C. Turn control knob clockwise. Oven operating light o This light will come on to indicate that oven’s...

  • Page 19: Warnings

    o You should pre-heat the oven and not place food inside of it until the oven operating light has gone off. You can choose not to pre- heat when using the fan oven mode; however you should extend the cooking time given on the food packaging by at least ten minutes.

  • Page 20: Shelf Positions

    o Important: Be careful when opening the door, to avoid contact with hot parts of the oven and steam. o When removing any item from the oven, you should ALWAYS use an oven glove. o Warning: Accessible parts may become hot during use. Young children should be kept well away from the oven when it is in use.

  • Page 21: Cleaning And Maintenance

    Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing any cleaning or maintenance process. o The oven should be thoroughly cleaned before it is operated for the first time and after each use.

  • Page 22: Replacing The Oven Bulb

    o Your appliance must be disconnected from your mains supply before replacing the oven light bulb, to avoid the possibility of electric shock. Replacing the oven bulb IMPORTANT: The oven must be disconnected from your mains supply before you attempt to either remove or replace the oven bulb.

  • Page 23: Removing The Oven Door For Cleaning

    Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows: o The hinges (A) have two movable bolts on them (B). o If you raise both of the movable bolts (B), then the hinges (A) are released from the oven housing.

  • Page 24: Removing The Inner Door Glass For Cleaning

    Remove the inner glass panel a. Glass door has two plastic fixed blocks. Use a slotted screwdriver to insert into the hole of the plastic fixed block and gently pry it. b. Remove the fixed block and the top ends of the plastic ventilation grid.
  • Page 25 c. Insert the heat sink into the upper left fixed block, d. Insert the upper right fixed block into the radiator panel. Fix the block into the iron frame and pay attention to the card position. INSTALLATION The installation must be carried out by a suitably qualified person, in accordance with the current version of the following.

  • Page 26: Electrical Connection

    o Electricity At Work Regulations. Electrical connection Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. WARNING: THIS APPLIANCE MUST BE EARTHED. o This appliance should be wired into a 10A double pole switched fused spur outlet, having 3 mm contact separation and placed in an easily accessible position adjacent to the appliance.

  • Page 27: Installing The Oven Into The Kitchen Cabinet

    o Care must be taken to ensure that the temperature of the mains supply cable does not exceed 50°C. o Regularly check the power cord for damage. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a danger or injury.

  • Page 28: Ventilation Requirements

    Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit.

  • Page 29: My Appliance Isn't Working Correctly

    My appliance isn’t working correctly o The oven isn’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly.
  • Page 30 o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. * You may get condensation in the oven cavity and forming between the oven door glasses.
