RS-232C
Transmission / Receiving Protocol
01. Power(Command : a)
To control Power On/Off of the Set.
Transmission
[k][a][ ][Set ID][ ][Data][Cr]
Data 0 : Power Off
Acknowledgement
[a][ ][Set ID][ ][OK][Data][x]
To show the status of Power On/Off.
Transmission
[k][a][ ][Set ID][ ][FF][Cr]
Acknowledgement
[a][ ][Set ID][ ][OK][Data][x]
Data 0 : Power Off
02. Input Select (Command : b) (Main Picture Input)
To select input source for the Set.
You can also select an input source using the SOURCE
button on the remote control.
Transmission
[k][b][ ][Set ID][ ][Data][Cr]
Data 2 : AV
4 : Component 1
5 : Component 2
Acknowledgement
[b][ ][Set ID][ ][OK][Data][x]
Data 2 : AV
4 : Component 1
5 : Component 2
Controlling the Multiple Product
1 : Power On
1 : Power On
6 : RGB (DTV)
7 : RGB (PC)
8 : HDMI (DTV)
9 : HDMI (PC)
6 : RGB (DTV)
7 : RGB (PC)
8 : HDMI (DTV)
9 : HDMI (PC)
A4
