  • Page 1 Black R6010 Model Pantone 534 Blue - 100/80/30/5 Moisture Detector Pantone 485 Red - 10/100/100/5 Pantone 123 Yellow - 0/27/100/ Instruction Manual reedinstruments 1-877-849-2127 | info@reedinstruments.com www.reedinstruments.com...

  • Page 2: Table Of Contents

    Alarm Set Mode ................5 Backlighting ................5 Moisture.Table.of.Comparison............6 Notes....................6 Blue - 100/80/30/5 Pantone 534 Blue Yellow - 0/27/100/0 Pantone 123 Yellow For.service.on.this.or.any.other.REED.product.or.information.on.other. REED.products,.contact.REED.Instruments.at.info@reedinstruments.com Red - 10/100/100/5 Pantone 485 Red Yellow - 0/27/100/0 Pantone 123 Yellow Blue - 100/80/30/5 Pantone 534 Blue 1-877-849-2127 | info@reedinstruments.com...

  • Page 3: Features

    Features •. Detects.moisture.content.in.building.materials.of.all.kinds,.as.well.as. detects.moisture.distribution.in.walls,.ceilings.and.floors •. Non-destructive.-.moisture.sensor.runs.smoothly.over.the.surface.being. tested.without.scratching.or.penetrating.the.surface •. Classifies.moisture.status.as:.dry,.at.risk.or.wet •. Display.Hold.button •. Max/Min.function.with.alarm.indication •. LCD.display.with.backlighting •. Low.battery.indication.with.auto.power.off Specifications Measuring.Range:. 0.0.to.100.0%.Moisture.Content Resolution:. 0.1%.M.C. Penetration.Depth:. 20.to.40mm Power.Supply:. 3.x.“AAA”.batteries Dimensions:. 242.x.63.x.30mm Weight:. 226g Optional.Accessories:. Soft.Carrying.Case.(Model.CA-05A) Blue - 100/80/30/5 Pantone 534 Blue Yellow - 0/27/100/0 Pantone 123 Yellow Red - 10/100/100/5 Pantone 485 Red...

  • Page 4: Instrument.description

    Instrument Description 1.. Moisture.sensor 2.. LCD.display 3.. MEAS.button 4.. UP/Backlighting.button 5.. Alarm.SET.button 6.. DOWN.button 7.. ON/OFF.button 8.. Battery.cover Display Description 1.. Low.Battery.indicator 2.. Data.Hold.symbol 3.. Current.moisture.value 4.. DRY.symbol 5.. RISK.symbol 6.. WET.symbol 7.. MAX.symbol 8.. MAX.moisture.value Blue - 100/80/30/5 Pantone 534 Blue 9..

  • Page 5: Operating.instructions

    Operating Instructions Taking a Measurement Turn.the.meter.ON.by.pressing.the. .button..Hold.the.meter.in.a.upright. position.so.the.ball.sensor.is.in.the.air.and.at.least.8-10cm.away.from.any. object..Press.the.MEAS.button.and.“CAL”.will.display.on.the.LCD.screen.. The.value.must.be.below.0.5.to.be.able.to.take.accurate.measurements.. If.the.reading.is.above.0.5.you.must.turn.the.meter.off.and.move.to.a.dry. area.to.calibrate..After.the.meter.is.calibrated.it.will.automatically.start.to. take.measurements..To.hold.the.current.measurement.press.the.MEAS.. button.and.the.data.hold.symbol.will.appear.on.the.LCD.screen... After.30.seconds.of.inactivity.the.meter.will.auto.power.off. Note: When.you.move.from.the.location.of.your.initial.calibration.you. must.re-calibrate.the.meter Alarm Set Mode To.change.the.RISK.and.WET.alarm.value.turn.on.and.calibrate.the.meter.. Press.the.MEAS.button.to.put.the.meter.in.data.hold.and.press.the.SET. button..The.RISK.symbol.will.appear.on.the.LCD.screen.and.the.value. which.the.RISK.alarm.is.set.to..To.change.the.alarm.value.press.the.UP. or.DOWN.buttons..Press.the.SET.button.to.save.your.setting.and.to. change.the.WET.alarm.value..The.WET.symbol.will.appear.on.the.screen. beside.the.WET.alarm.value..To.change.the.WET.alarm.value.press.the. UP.or.DOWN.buttons..Press.the.SET.button.to.save.the.WET.alarm.value. and.to.return.to.data.hold.mode..If.the.moisture.measurement.exceeds. the.RISK.alarm.setting.the.meter.will.beep.every.second..If.the.moisture. measurement.exceeds.the.WET.alarm.setting.the.meter.will.beep.every. half.second. Note: The.RISK.alarm.value.is.between.0-50..The.default.setting.is.30 The.WET.alarm.value.is.between.50-100..The.default.setting.is.60 Backlighting Blue - 100/80/30/5 Pantone 534 Blue When.the.meter.is.in.data.hold,.press.the.UP.button.to.turn.the.backlighting.

  • Page 6: Moisture.table.of.comparison

    If.the.thickness.of.the.material.being.measured.is.less.than.20mm.the. . reading.may.not.be.accurate.due.to.conflicting.values •. If.the.BAT.symbol.appears.on.the.LCD.screen,.the.batteries.need.to. be.replaced Blue - 100/80/30/5 Pantone 534 Blue Yellow - 0/27/100/0 Pantone 123 Yellow For.service.on.this.or.any.other.REED.product.or.information.on.other. Red - 10/100/100/5 Pantone 485 Red Yellow - 0/27/100/0 REED.products,.contact.REED.Instruments.at.info@reedinstruments.com Pantone 123 Yellow Blue - 100/80/30/5 Pantone 534 Blue 1-877-849-2127 | info@reedinstruments.com...
