- Page 1 INSTRUMENTS R9100 R9100 Model Ultrasonic Leak Detector Leak Detector INSTRUMENTS Instruction Instruction Manual reedinstruments REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
-
Page 2: Table Of Contents
Operating Instructions ..............5 Leak Detector ................5 Transmitter .................. 5 Battery Replacement ..............6 Safety • Do not use near an electrical appliance which emits electromagnetic waves • If not used for a long period, remove the battery • Do not operate if the leaking gas or liquid is explosive or flammable • Do not operate around explosive or flammable gas, vapor, or dust Features • Locates leaks generated by pressure, vacuum, water, gas or air • Visible (LED) and Audible (ticking) alarms assist in pinpointing leaks • User adjustable sensitivity wheel • Includes earphones, carrying case and batteries reedinstruments INSTRUMENTS INSTRUMENTS REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 3: Applications
Leak Detector (Receiver) Frequency Response: 40 kHz ±2kHz Sensitivity Adjustment: Yes (wheel) Alarm: Audible (Ticking) / Visual (LED) Earphone Jack: Yes (Earphones included) Transmitter Output Frequency: 40 kHz Power Indicator: General Specifications Power Supply: 2 x 9V Batteries Product Certifications: CE, RoHS Operating Temperature: 32 to 104°F (0 to 40°C) Storage Temperature: -4 to 122°F (-20 to 50°C) Dimensions: Receiver: 7.6 x 2 x 1.2" (192 x 50 x 30 mm) Transmitter: 3.9 x 2.3 x 1.1" (101 x 59 x 28 mm) Weight: Receiver: 4.1oz (115g) Transmitter: 3.2oz (90g) reedinstruments INSTRUMENTS INSTRUMENTS REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 4: Instrument Description
Instrument Description 1. Detector 2. POWER LED Indicator 3. LEAK LED Indicator 4. Sensitivity Wheel: Rotate it upwards to decrease sensitivity. Rotate it downwards to increase sensitivity. 5. TEST Button: Press and hold this button to turn the detector ON. Release the button to turn the detector OFF. 6. Headphone Jack 1. POWER Button 2. Speaker: Used to emit ultrasonic sound. 3. POWER LED Indicator reedinstruments INSTRUMENTS INSTRUMENTS REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 5: Operating Instructions
4. Once the leak is located and repaired, retest with the detector to confirm there is no leak. Notes • There are many factors involved in the ultrasonic leak detection, such as the pressure within the vessel under test, hole shape, hole size, temperature, etc. In some cases, the ultrasonic sound emitted is very weak. Always start by setting the detector’s sensitivity to the highest level at the beginning of the test. • If the detected ultrasonic sound is too intense so that it is impossible to pinpoint the leak because the “ticking tone” is too high, decrease the sensitivity. • As ultrasonic sound attenuates rapidly when it travels over a distance, move the detector as close as possible to the suspected leak. Remember to decrease the sensitivity if necessary. During location, move the probe slowly. Transmitter 1. Turn on the transmitter. If the “POWER” LED does not light, replace the battery. 2. Place the transmitter inside the compartment to be tested, then close the compartment. This ultrasonic sound emitted by the transmitter will pass through any orifice or faulty seal. 3. Scan the outside surface of the compartment with the receiver. The ultrasonic sound escaping from the compartment will be detected. reedinstruments INSTRUMENTS INSTRUMENTS REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 6: Battery Replacement
Battery Replacement To replace the battery, slide the battery cover open and replace the battery with a new 9V battery. Reinstall the battery cover. For service on this or any other REED product or information on other REED products, contact REED Instruments at info@reedinstruments.com reedinstruments INSTRUMENTS INSTRUMENTS REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
