ADTRAN Total Access 362R Manual page 4

To terminate the POTS lines on the two‐screw terminal bridges
complete the following:
1. Trim each wire to length and strip insulation. Identify each
pair in the service cable.
2. Loosen the screws from the
3. Wrap the appropriate wire around the appropriate screw
and tighten the screws to secure the connections.
POTS can also be connected directly to the RJ‐11 jack. In this case
the two‐screw terminal bridges become isolated and are not used.
RF Connection
Route the RF cable through the large grommet at the bottom of
the enclosure and attach it to the RF connector located on the
bottom the Electronics Module.
Ethernet Connection
The SFU ONT supports up to two 1 Gigabit (10/100/1000) Base‐T
connections. The cable used should be rated CAT 5 or 6. If
Ethernet cables are not available, use the following procedure and
table to create the Ethernet cables:
1. Trim the insulation for the subscriber Ethernet cable.
2. Connect the wires per the following table using an RJ‐45
Crimper:
Ethernet RJ-45 Pin-out
Pin Name Description
1 TRD0+ Transmit/Receive Positive
2 TRD0‐ Transmit/Receive Negative
3 TRD1+ Transmit/Receive Positive
4 TRD2+ Transmit/Receive Positive
5 TRD2‐ Transmit/Receive Negative
6 TRD1‐ Transmit/Receive Negative
7 TRD3+ Transmit/Receive Positive
8 TRD3‐ Transmit/Receive Negative
3. Insert the terminated connector in the appropriate
socket.
Link activity can be determined using the built‐in LEDs on the
connectors. Refer to the following table:
Label Status Description
Link
Off Link is down or Administratively shut down
Green
10/100/1000 link is up
Activity
Off No activity, or Administratively Shut Down
Yellow
TX or Rx activity
Flashing
For more information, refer to the Installation and Maintenance Guide (P/N 61187715G1-5)
available online at www.adtran.com.
Warranty: ADTRAN will replace or repair this product within the warranty period if it does not
meet its published specifications or fails while in service. Warranty information can
be found online at www.adtran.com/warranty.
©2011 ADTRAN, Inc. All Rights Reserved.
TIP RING
(green) and (red).
Color Code
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
ETH
O S
PERATIONAL PECIFICATIONS
♦
Wavelengths
◊
Upstream: 1310 nm
◊
Downstream: 1490 nm
◊
Downstream RFTV: 1550 nm
◊
Upstream RF Return: 1610 nm
◊
Output Wavelength: 1600 to 1620 nm
◊
Optical Output Power: 1 dBm minimum
♦
Dimensions
◊
Height: 12.00 inches (305 mm)
◊
Width: 9.7 inches (246 mm)
◊
Depth: 4.00 inches (102 mm)
♦
Weight: 3.8 lbs (1.7 kg)
♦
Voltage Range: 10.5 VDC to 15 VDC
♦
Maximum Current: 1.5 Amps
♦
Environmental:
◊
Operational Temperature Range: –40°C to +65°C
◊
Storage Temperature Range: –40°C to +85°C
◊
Up to 95% humidity, non‐condensing
M
AINTENANCE
The 362R SFU does not require routine hardware maintenance for
normal operation. ADTRAN does not recommend that repairs be
attempted in the field. Repair services may be obtained by
returning the defective unit to ADTRAN. Refer to the warranty
for further information. Field support for software is provided
through upgrade facilities.
S R
AFETY AND EGULATORY
Refer to the Safety and Regulatory Compliance Notice for this
product (P/N 61187715G1‐17) for detailed safety and regulatory
information.
Consultez lʹavis sur la sécurité et la conformité à la réglemen‐
tation pour ce produit (61187715G1‐17) pour obtenir des
renseignements détaillés sur la sécurité et la réglementation.
Ausführliche Sicherheits‐ und regulatorische Informationen sind
in der Konformitätserklärung zur Sicherheit und Einhaltung von
Normen zu diesem Produkt (61187715G1‐17) aufgeführt.
C A U T I O N ! C A U T I O N
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
C
OMPLIANCE
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
PRICING AND AVAILABILITY 1.800.827.0807
*61187715G1-22B*
