Chapter 1 / 6

Unpacking the Components

The following actions should be taken by the forwarder upon delivery of the
system components.
· Removal of the outer packing material.
The individual boxes inside must not be opened by the forwarder.
· Taking out the accessories or boxes and storing them in a safe place.
· The ADC Compact Plus must be taken off the pallet and transported to the
installation site.
· Disposal of the packing material.
For unpacking the machine, an area of minimal 200 x 350 cm is required.
For lifting the machine off the pallet an area of minimal 100 x 500 cm is
required.
If the available space at the installation site is limited, the machine can be
unpacked beforehand and rolled to the installation site.

Checking the Accessory Kit

The following actions have to be done by the FSE (Field Service Engineer) at
the customer site.
· Checking the scope of delivery:
Compare the inventory of every component with the packing list which
specifies the complete scope of delivery.
Pieces Description
1 ADC Compact Plus Digitizer
1 Base plate
1 Installation Instructions
1 Installation Report
1 ADC Compact Plus user manual information
1 Certificates
6 Floppies
1 Cu-Filter
1 UTP network cable (2 x RJ45 connection)
1 Allen key, size 8
1 Test image CD
1 Connection cable (3 core I-2500-S)
1 Connection cable (Hospital Grade)
2 Adjustable bases, riveted
