Controls, Connections and Setup Procedures
DD+DIS064.02E
A
D
B
C
514601EB.CDR
Figure 3
A: Cut the cable tie on both cassette units.
B: Cut the cable tie on the deflector of the output buffer.
C: Cut the cable tie on the feed gate of the input buffer.
D: Screw on the two adjustable bases (7mm socket wrench).
Edition 1, Revision 4
ADC Compact Plus
Chapter 1 / 9
(Type 5146)
