Controls, Connections and Setup Procedures
Removing shipping brackets from the scan unit
A
B
Figure 6
A: Remove the two allen screws at the rear of the machine securing the scan
unit.
B: Mount the light tight tin plate (included in accessory kit) by fastening six
Phillips screws.
Remove the polystyrene blocks jammed at the feed- and exit rollers of the
scan unit (2 pieces).
ADC Compact Plus
514601ek.cdr
(Type 5146)
Chapter 1 / 13
