Summary of Contents for Vacmaster RESPIRA UC0412EUK
-
Page 4: Table Of Contents
Recycling and Disposal ........................17 Guarantee............................18 ® Thank you for purchasing this Vacmaster vacuum cleaner. This is a vacuum cleaner intended for domestic use only and suitable for indoor use within a normal household environment for light, dry dust and debris. -
Page 5: Safety Information
SAFETY INFORMATION READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating manual with due care. Keep this manual in a safe place so that the information is always available. - Page 6 • Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord. • Do not use with damaged cord, plug or other parts. • Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp edges or corners.
-
Page 7: Unpacking And Product Features
- risks associated with the material to be picked up. - safe disposal of the picked up material. UNPACKING AND PRODUCT FEATURES Handle Power Cable Dust Bin Release Button Upper Cord Hook Carry Handle Upper Hose Storage Dust Bin Lid Release Button Flexible Suction Hose Dust Bin Accessory Storage... -
Page 8: Assembly
ASSEMBLY A flat headed screwdriver is required for part of the assembly process. 1. Remove all the contents from the packaging; make sure you have all contents as listed on page 7. 2. Remove the pre-installed screw bolt with a screwdriver or a coin. Insert the handle assembly into the main body and secure with the screw bolt (Fig. -
Page 9: Operation
OPERATION CAUTION: Moving parts! To reduce the risk of personal injury, DO NOT touch the brushroll when vacuum cleaner is turned on. Contacting the brushroll while it is rotating can cut, bruise or cause other personal injuries. Always turn off before maintenance. Use caution when operating near children or pets (Fig. - Page 10 The brushroll indicator status light: Colour Status Green The brushroll is spinning and working as intended. There is a jam in the brushroll area. Turn off and unplug the vacuum. Remove any blockages in the nozzle. No Light The brushroll is not active. ABOVE FLOOR MODE 1) Place the vacuum cleaner in the upright locked position.
-
Page 11: Maintenance
MAINTENANCE IMPORTANT! Unplug the power cord from the supply before performing any maintenance. WARNING: Disconnect electrical supply before servicing or cleaning the vacuum cleaner. Failure to do so could result in electrical shock or personal injury. WARNING: There are sharp edges inside the motorised floor head to prevent hair entanglement. - Page 12 NOTE: Make sure dust bin is free of debris before opening. 1) Remove the dust bin. 2) Press the dust bin lid release button (Fig. 23). 3) Grasp the pre-filter ( ) and rotate counterclockwise (Fig. 24). 4) Clean pre-filter by gently tapping. NOTE: If necessary, rinse with cold water only.
- Page 13 If you see any hair wrapped around the brushroll, continue cleaning, ensuring the On/Off switch is in 'II' position with the brushroll rotating on low pile carpets or tile floors. Hair will be removed from the WrapFree brushroll and be sucked into the dust bin. If you hear a sound change when vacuuming, check for blockages or objects caught in the brushroll.
-
Page 14: Troubleshooting
Failure to do so could result in electrical shock or personal injury. Cleaning Performance Vacmaster vacuum cleaners are tested for endurance. If your motor is operating, then the most likely cause for a loss in suction is a blockage or an opening in the vacuum. - Page 15 PROBLEM POSSIBLE CAUSE SOLUTION Check dust bin for correct installation Dust bin is not installed correctly. and ensure it is snapped firmly in place. Check the hose and attachments for The hose or attachments are not correct installation and ensure they installed correctly.
- Page 16 PROBLEM POSSIBLE CAUSE SOLUTION Turn the vacuum cleaner off and unplug it. Allow the vacuum cleaner Thermal protector is activated. to cool for a minimum of 50 minutes. Plug in vacuum and turn it on. Vacuum turns off Reinsert the power cord plug fully into on its own.
-
Page 17: Technical Data
TECHNICAL DATA Model Number UC0412EUK / UC0413EUK Voltage 220-240 V ~ Frequency 50 Hz Power Input 800 W RECYCLING AND DISPOSAL This marking indicates that this product should not be disposed with other household wastes. The machine must be delivered in rigid packaging to avoid damage during transportation. -
Page 18: Guarantee
All Vacmaster products are carefully checked, tested and are subject to our stringent quality control process. Your Vacmaster appliance is automatically covered by an initial limited 2-year (24 month) guarantee against material and/or workmanship defects from the date of purchase. - Page 19 What is not covered by the guarantee? • Guarantee applies to the original owner and is not transferable nor does it carry a cash value. • Appliances purchased from an unauthorized dealer. • Use of appliance not in accordance with the product instruction manual including careless operation or handling, misuse, abuse and/or lack of regular maintenance.
- Page 22 Ⅲ Ⅰ Ⅱ Ⅳ UC0412EUK Ⅱ Ⅲ Ⅰ UC0413EUK...
- Page 23 2 15 2 16 Ⅰ Ⅱ Ⅱ Ⅰ Ⅰ Ⅰ...
- Page 24 UC0412EUK / UC0413EUK Suzhou Cleva Electric Appliance Co., Ltd. No.8 Ting Rong Street Suzhou Industrial Park, Suzhou Jiangsu Province, China www.cleva-europe.com Made in P.R.C...
