Summary of Contents for Vacmaster UC0902EHUK
-
Page 4: Table Of Contents
Recycling and Disposal ........................17 Guarantee............................18 ® Thank you for purchasing this Vacmaster vacuum cleaner. This is a vacuum cleaner intended for domestic use only and suitable for indoor use within a normal household environment for light, dry dust and debris. -
Page 5: Safety Information
SAFETY INFORMATION READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating manual with due care. Keep this manual in a safe place so that the information is always available. - Page 6 • Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord. • Do not use with damaged cord, plug or other parts. • Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp edges or corners.
-
Page 7: Unpacking And Product Features
UNPACKING AND PRODUCT FEATURES Handle Suction Control Wand Handle Release Button Dust Bin Release Button Accessory Storage Carry Handle Connection Hose Dust Bin Lid Release Button Lift Off Release Pedal Dust Bin Wand Release Button Exhaust Filter Cover On/Off Switch Task Lights Flexible Suction Hose Motorised Floor Head... -
Page 8: Assembly
ASSEMBLY 1. Remove all the contents from the packaging; make sure you have all contents as listed on page 7. 2. Insert the wand into the main body until you hear a ‘click’ (Fig. 1). 3. Insert the handle into the wand until you hear a ‘click’ (Fig. 2). To remove: Press handle release button and pull up on handle. -
Page 9: Operation
OPERATION CAUTION: Moving parts! To reduce the risk of personal injury, DO NOT touch the brushroll when vacuum cleaner is turned on. Contacting the brushroll while it is rotating can cut, bruise or cause other personal injuries. Always turn off before maintenance. Use caution when operating near children or pets (Fig. - Page 10 The brushroll indicator status light: Colour Status Green The brushroll is spinning and working as intended. There is a jam in the brushroll area. Turn off and unplug the vacuum. Remove any blockages in the nozzle. No Light The brushroll is not active. ABOVE FLOOR MODE 1) Place the vacuum cleaner in the upright locked position.
-
Page 11: Maintenance
3) Upholstery Tool Use the upholstery tool for cleaning fabric surfaces such as fabric sofa and bedsheets (Fig. 21). 4. Suction Control To assist with push/pull force of the vacuum on surfaces, the suction control valve can be opened to help reduce suction. Note that for best cleaning results, the suction control valve must be fully closed. - Page 12 1) Press the dust bin release button to remove the dust bin from the main body (Fig. 23). 2) Remove any debris that might be located in the suction port ( ) (Fig. 24). 3) Position dust bin over the waste receptacle. Press down on the dust release button ( ) to open lid (Fig.
- Page 13 NOTE: DO NOT operate without exhaust filter installed. DO NOT wash in the dishwasher. DO NOT install the filter if damp. 4) Reinstall the exhaust filter into the vacuum cleaner until a click is heard (Fig. 33). 5) Insert the exhaust filter cover tabs ( ) into the upper slots ( ) and lock the exhaust filter cover into place by pressing the lower part of the cover until a click is heard (Fig.
-
Page 14: Troubleshooting
Failure to do so could result in electrical shock or personal injury. Cleaning Performance Vacmaster vacuum cleaners are tested for endurance. If your motor is operating, then the most likely cause for a loss in suction is a blockage or an opening in the vacuum. - Page 15 PROBLEM POSSIBLE CAUSE SOLUTION Check the hose and attachments for The hose or attachments are not correct installation and ensure they installed correctly. are firmly in place. Check dust bin for correct installation Dust bin is not installed correctly. and ensure it is firmly in place. Full or clogged dust bin.
- Page 16 PROBLEM POSSIBLE CAUSE SOLUTION Exhaust filter cover is installed Position exhaust filter cover correctly. incorrectly. Follow instructions on page 12-13. Check for and remove any clogs and Sound changes. Air path is blocked. clean the air path. Follow instructions on page 13. Attachments in use restrict air Check attachments for fuzz, lint, pet flow.
-
Page 17: Technical Data
TECHNICAL DATA Model Number UC0902EHUK Voltage 220-240 V ~ Frequency 50-60 Hz Power Input 800 W RECYCLING AND DISPOSAL This marking indicates that this product should not be disposed with other household wastes. The machine must be delivered in rigid packaging to avoid damage during transportation. -
Page 18: Guarantee
All Vacmaster products are carefully checked, tested and are subject to our stringent quality control process. Your Vacmaster appliance is automatically covered by an initial limited 2-year (24 month) guarantee against material and/or workmanship defects from the date of purchase. - Page 19 What is not covered by the guarantee? • Guarantee applies to the original owner and is not transferable nor does it carry a cash value. • Appliances purchased from an unauthorized dealer. • Use of appliance not in accordance with the product instruction manual including careless operation or handling, misuse, abuse and/or lack of regular maintenance.
- Page 22 2 18 2 19 Ⅰ Suction Control Ⅱ Ⅱ Ⅰ Ⅱ Ⅰ Ⅰ Ⅱ...
- Page 24 UC0902EHUK Suzhou Cleva Electric Appliance Co., Ltd. No.8 Ting Rong Street Suzhou Industrial Park, Suzhou Jiangsu Province, China www.cleva-europe.com Made in P.R.C...
