Parts List - Exploded View _________________________________________________ thank you for purchasing this Vacmaster wet/dry vacuum cleaner. Feel confident that with Vacmaster you are obtaining a high quality product engineered for optimal performance. this vacuum is capable of picking up liquids and dry materials.
ARRANtY damage to the appliance and cause the guarantee to become void. • If the power cord is damaged, it must be completely replaced along by customer Vacmaster takes pride in producing a high quality, durable product. This service. Vacmaster product carries a limited two () year warranty against defects in •...
Page 4
appliance. • Never use the appliance when you are under the influence of medication, alcohol or pECiFiCAtiONS drugs, if you are currently under medical care, or if you are tired. • Check the appliance and the power cord regularly for any possible damage. Don’t Motor: 230V-50Hz use damaged appliances.
ENERAL ASSEMBLY iNStRUCtiONS Handle Cord Rewind Button WARNiNG: Do noT plUg In poWEr CorD To poWEr oUTlET, maKE SUrE Power Switch Power Head plUg IS DISConnECTED BEforE aSSEmBlIng THE WET/Dry VaC UnpaCKIng yoUr WET/Dry VaCUUm & gEnEral aSSEmBly UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY Tool Caddy 1.
Double insulation eliminates the need for the three wire grounded power cord 3. Place filter retainer on top of cartridge filter and tighten by turning the retainer and grounded power supply system. handle clockwise. (fig. 3) 4. Optional, for improved dust filtering, fit collection dust bag flange onto the inlet stub, taking care not to damage the bag.
action when the container reaches its maximum capacity. you will notice an increase in motor speed. When this happens, turn off the machine, disconnect Et-VACUUM OpERAtiON from power supply, and drain the liquid into a suitable receptacle or drain. To continue vacuuming, refit the container with power head. after wet WARNiNG: BE SURE tO READ, UNDERStAND, AND AppLY iNFORMAtiON, vacuuming, turn the machine off and remove plug from power supply.
only. a dry cartridge filter is necessary to pick up dust. If the cartridge filter Installing and Cleaning HEpa filter is wet, it will clog quickly and be very difficult to clean. Handle the filter 1.Verify that the power cord is disconnected from the outlet. (fig.1) carefully when removing it for cleaning and replacing it.
3. Allow filter to air dry before installing and using again. ARtS LiSt -ExpLODED ViEW ROUBLESHOOtiNG Symptom possible Causes Corrective action 1) No power supply. 1) Check power supply – cord, breakers, fuses. Vacuum will not 2) Faulty power cord. 2) Unplug and check the operate power cord.
Page 10
VF1515HJ Manual parts List Key number Drawing number Description Quantity GD41BX.40.01 Handle VH60P1.16.00 Power Head Assembly WODQ10.01.12 Power Switch VH60P1.17.00 Float & Filter Cage FV9543.03.03 Cartridge Filter FV9543.03.20 Filter Retainer TVQTGL.17.00 Left Rear Wheel VH60P1.20.01 Container TVQTJL.08.00 Caster FV9241.04.01 Tool Caddy TVQTDK.11.00...
Page 11
Feilsøking ______________________________________________________________ 18 Deleliste - diagram _______________________________________________________ 19 takk for at du kjøpte denne Vacmaster våt/tørrsugeren. Du kan være trygg på at du har skaffet et produkt av høy kvalitet som er utformet for optimal ytelse. Denne maskinen er i stand til å suge opp både væske og tørt materiale.
Bruk av feil støvpose eller feilaktig montert støvpose kan forårsake skader på maskinen, og oppheve garantien. Vacmaster er stolte av å levere slitesterke produkter av høy kvalitet. • Hvis strømledningen er skadet, må den byttes av autorisert elektriker. Dette Vacmaster -produktet leveres med en begrenset -årig garanti som •...
Page 13
• Sjekk maskinen og strømledningen jevnlig, og se etter eventuelle skader. En skadet maskin må ikke brukes. EKNiSKE DAtA • Prøv ikke å reparere maskinen selv. Kontakt alltid en autorisert elektriker når det er behov for reparasjoner. Skadde strømledninger må alltid byttes straks av Motor: 230V-50Hz produsenten eller autorisert elektriker.
ENERELLE MONtERiNgSiNStRUKSER Håndtak Bryter for inntrekking av strømledning ADVARSEL: IKKE KOBLE TIL STRØM FØR DU SETTER SAMMEN STØVSUGEREN. Strømbryter Motorenhet UTPAKKING OG MONTERING AV STØVSUGER 1. Pass på at strømledningen ikke er koblet til. (Figur 1) 2. Løsne låseklemmene. (Figur 2) 3.
med klokken. (Figur 3) 4. For mer effektiv støvfiltrering kan du feste flensen på støvposen over inntaksåpningen. Pass på at du ikke skader posen. (Figur 4) 5. Sett motorenheten tilbake på beholderen slik at den passer med låseklemmene, og fest. (Figur 5) INSTRUKSER FOR BRUK: TØRRSUGING 6.
slippe gjennom luft. Maskinen er utstyrt med en flyteventil som stopper innsugingen når beholderen er full. Du vil merke en økning i motorhastigheten. åtSUgiNg Når dette skjer, slå av maskinen, koble fra strømmen, og tøm væsken i en egnet beholder eller sluk. For å fortsette å suge, sett på plass motorenheten ADVARSEL: Sørg for å...
rengjøre. Håndter filteret med varsomhet ved rengjøring og bytting. Sjekk om INSTALLASJON OG RENGJØRING AV HEPA-FILTER det er små hull eller rifter i filtrene, et lite hull kan slippe gjennom støv. Ikke 1. Pass på at strømmen er koblet fra. (Figur 1) bruk et filter med hull eller rifter, bytt det straks.
ELELiStE – DiAgRAM EiLSøKiNg SYMPTOM MULIG ÅRSAK MULIG LØSNING 1) Får ikke strøm. 1) Sjekk strømforsyning – ledning, brytere, sikringer. 2) Skade på strømledning. 2) Koble fra og sjekk Støvsugeren strømledning. Hvis den er 1 1 starter ikke. skadet, må den repareres av en elektriker.
Page 19
VF1515HJ Deleliste Nummer Navn Beskrivelse Antall GD41BX.40.01 Håndtak VH60P1.16.00 Motorenhet WODQ10.01.12 Motorbryter VH60P1.17.00 Filterbur FV9543.03.03 Innsatsfilter FV9543.03.20 TVQTGL.17.00 Venstre bakhjul VH60P1.20.01 Beholder TVQTJL.08.00 Forhjul FV9241.04.01 Holder for tilbehør 19 19 TVQTDK.11.00 Låseklemme TVQTGL.18.00 Høyre bakhjul FV8804.01.00 Slange FV8772.02.01 Munnstykke for sprekker FV8774.01.01...
