Technical specifications
Vibration channel (VIB)
Measuring range:
Resolution:
Frequency, lower limit:
Frequency, upper limit:
Measuring time:
Alarm limits:
Alarm delay:
Fault indication:
Transducer type:
Shock pulse channel (SPM)
Shock pulse method:
Measuring time:
Measuring range:
Resolution:
Alarm limits:
Alarm delay:
Fault indication:
Transducer type:
This product must be disposed as electronic waste and is marked with a crossed-out wheeled bin
symbol in order to prevent it being discarded with household waste.
When once the life cycle of the product is over You can return it to Your local SPM representative
for correct treatment, or dispose it together with your other electronic waste.
© Copyright SPM Instrument AB. ISO 9001:2000 certified. Technical data are subject to change
without notice.
SPM Instrument AB • Box 504 • SE-645 25 Strängnäs • Sweden
Tel +46 152 225 00 • Fax +46 152 15075 • info@spminstrument.se • www.spminstrument.com
Machine Guard MG4-REF11A
0.5 to 49.9 mm/s RMS (0 to 1.9 inch/s RMS)
0.1 mm/s (0.01 inch/s)
10 Hz
1000 Hz
programmable 1 to 15 s
2, programmable, A1 (max) and A2 (min)
0 to 600 seconds, steps of 2 s
transducer line test for short and open circuit
IEPE (ICP ) with bias 2 to 18 V DC and sensitivity 0.9 to 12.0
®
mV/m/s , type SLD or TRV-18/19/20/21 with isolated installation
2
foot TRX-18/19
dBm/dBc
approx. 0.4 s
0 to 99 dBsv
1 dB
2, programmable, A1 (max) and A2 (min)
0 to 600 seconds, steps of 2 s
transducer line test of measuring circuit quality, every 2 min.
SPM 42000
