Part 2: Install The Power Adapter - Garage Smart Basic MyLifter Installation And Operation Manual

Part 2: Install the Power Adapter

Find a suitable location to mount the power adapter to the wall or the celing. Confirm
that the AC cable will reach a power outlet and the DC cable will reach your MyLifter.
1. Find the closest outlet on the wall or ceiling.
2. Use a stud finder to find a suitable mounting location near the closest outlet.
3. Use a pencil to mark two points exactly two inches apart to indicate where you
will place the wall mount screws.
4. Use a Philips head screwdriver to screw the wall mount screws into the two
marks you made. DO NOT screw in the wall mount screws all the way. Allow the
screw heads to produce from the wall or the ceiling by about 1/4 inch.
5. Align the two large holes on the back of the adapter over the wall mount screw
heads and slide the power adapter to lock it into place.
