Garage Smart UNIVERSAL LIFTER Installation And User Manual

Hide thumbs Also See for UNIVERSAL LIFTER:

Advertisement

Quick Links

Download this manual
Installation and User Guide
Garage Smart support –
support.garagesmart.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNIVERSAL LIFTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garage Smart UNIVERSAL LIFTER

Summary of Contents for Garage Smart UNIVERSAL LIFTER

  • Page 1 Installation and User Guide Garage Smart support – support.garagesmart.com...

  • Page 2: Table Of Contents

    Contents Limited Lifetime Warranty ..........................3   Safety Information............................... 5   FCC Statement ..............................6   About the Universal XL Lifter ........................7   Parts Identifier .............................. 7   Installation Overview............................8   Installing the Universal XL Lifter ......................8  ...

  • Page 3: Limited Lifetime Warranty

    God, or failure to follow the Owner’s Manual. This warranty is the only one we will give on your Garage Smart Product. There are no other express warranties.
  • Page 4 Lifter system voids the warranty. Unauthorized repair or modification voids the warranty. The Lifter system is intended for personal, indoor, home use. Garage Smart does not warrant its lift system for commercial use, and any such use voids the warranty.

  • Page 5: Safety Information

     Do not stand under the Universal Lifter or items lifted by the system.  Do not use the Universal Lifter to lift people or animals.  Do not use the Universal Lifter to lift or lower items when people or animals are under the system.

  • Page 6: Fcc Statement

    FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 7: About The Universal Xl Lifter

    The Universal Lifter is designed to lift large, bulky items and store them safely on your garage ceiling. You can use the Universal Lifter to lift a bike, a cargo top, a wheelbarrow, or other uniquely shaped items up to 100 pounds.

  • Page 8: Installation Overview

    Installation Overview The Universal Lifter kit can lift a total of 100 pounds, which includes the weight of the Universal Lifter frame. Before you lift an item, make sure that its weight combined with the weight of the frame does not exceed 100 pounds.
  • Page 9 Part 1: Determine where to install the Universal Lifter To begin you want to make sure that the object you want to lift is not too big for the space where you want to lift it. 1. Place the item on the garage floor in the area where you will be lifting it .
  • Page 10 7. Use these same measurements to mark your starting point on the garage ceiling. The starting point will be used to help you find the surrounding ceiling joists where you will install your Smart Track.
  • Page 11 Part 2: Install the Smart Track The orientation of the Universal Lifter frame and the item you want to lift determine how you will need to install the Smart Track. If your joists run parallel to the item and the Universal XL Frame, you will need to install the Smart Track along the joist that is nearest to your starting point as shown below.
  • Page 12 1. Use a stud finder to find the joist that is nearest to your starting point. 2. After you have found the nearest joist, use the stud finder to find and mark the center of it. a. Mark the left edge of the joist. b.
  • Page 13 Whenever possible, use two lags screws in each section of Smart Track to ensure a secure installation. WARNING Failure to mount the Smart Track and the Universal Lifter to secure ceiling joists or rafters could result in property damage, serious personal injury, or death.
  • Page 14 Excessively angled or crossed cables could result in damage to the MyLifter motor and to your property and could cause personal injury. 4. Plug in one end of the DC Power Cable into the Garage Smart Power Adapter.
  • Page 15 5. Install the power adapter anywhere on the Smart Track. The universal mount attached to the bottom of the power adapter lets you easily slide and snap it into place on the track. 6. Plug the other end of the DC Power Cable into the MyLifter unit. 7.
  • Page 16 c. You can also organize cables by winding the excess cable around the power adapter housing. Excess cable can also be stowed in the Smart Track d. Use the track covers to support and organize the cables stowed in the Smart Track.

  • Page 17: Using The Mylifter App

    Using the MyLifter App The MyLifter app is paired with your MyLifter unit using a Bluetooth® connection. Be sure to enable your mobile device’s Bluetooth capabilities before attempting to pair with your lifter. 1. Download the MyLifter app from the App Store or Google Play. 2.
  • Page 18 5. On the home screen, tap Edit in the upper right-hand corner of the screen. The button name changes from Edit to Exit and the app enters Edit Mode. In Edit Mode you can rename the lifter or delete it if you need to. 6.
  • Page 19 The following graphic gives you an overview of the Device Control screen interface with brief descriptions of its features. 10. On the Device Control screen, press and hold the Manual Lower arrow to let out the cable enough so you can: a.
  • Page 20 CAUTION Make sure the cable is as vertical as possible from the lifter to the first pulley and from the second pulley to the carabiner. Improperly aligned cables could result in damage to the MyLifter motor and to your property and could cause personal injury.
