INSTALLATION HARDWARE
①
8 Standard VESA Bracket
Screws
④
8 Extended VESA Bracket
Screws
⑦
⑨
10mm Hex Key
2
②
8 Plastic Spacers
⑤
2 VESA Brackets
Clamp Mount
⑩
⑪
16mm Wrench
⑧
Bolt-Through Mount
Bolt-Through Plate
Bolt-Through Adapter
③
4mm
Hex Key
Hex Key
⑥
NOTE: 4mm and 5 mm Hex Keys can
be found under the plastic base cover.
Sliding Desk Mount
⑫
⑬
Bolt-Through Bolts
5mm
