BFT D113745-00001 Quick Reference

wiring peripheral devices

PHOTOCELL SENSOR AND/OR LOOP
DETECTOR WIRING (CLOSING OBSTRUCTION)
-----------
POWER + 51
-----------
POWER - 50
-----------
RELAY COMMON 70
-----------
RELAY N.C. 72
PROGRAMMING: LOGIC > SAFE 1 = 004
"OPEN ONLY" DEVICE
(RADIO RECEIVER, KEYPAD , ETC.)
-----------
POWER + 51
-----------
POWER - 50
-----------
RELAY COMMON 60
-----------
RELAY N.O. 62
PROGRAMMING: LOGIC > IC 2 = 002
external lock wiring
P/N: KRELAY24V IS REQUIRED (NOT INCLUDED)
white PROGRAMMING: LOGIC > AUX 3 > 007 = SOLENOID LOCK
26
red
27
krelay24v
krelay24v

fUSE VALUES:

F1 = 2.5 a SLOW-BLOW
F2 = 3.15 A SLOW-BLOW
█ █ █ █ █ █ █ █ █ █ █ █ █
10 11 14 15 20 21 26 27 40 41 42 43 44
"START COMMAND" DEVICE
(SINGLE PUSH-BUTTON,RADIO RECEIVER, KEYPAD ,
ETC.)
-----------
POWER + 51
(ONLY IF POWER
IS REQUIRED)
-----------
POWER - 50
-----------
RELAY COMMON 60
-----------
RELAY N.O. 61
SHADOW LOOP SENSOR WIRING
(PREVENTS THE GATE FROM STARTING
TO CLOSE)
PROGRAMMING: LOGIC > SAFE 2 = 004
> AUX 3 = 006
-----------
POWER + 51
instal jumpers
-----------
POWER - 50
-----------
RELAY COMMON 70
-----------
RELAY N.C. 74
26
27
008 = MAGLOCK
blue
+ POWER SUPPLY *MAGLOCK ONLY
orange
+ POWER SUPPLY *SOLENOID LOCK ONLY
- POWER SUPPLY
- LOCK POWER
yellow
+ LOCK POWER
thalia connection terminals
█ █ █ █ █ █ █ █ █ █ █ █
45 50 51 52 60 61 62 70 71 72 73 74
www.BFTGateOpeners.com | (800) 878-7829 | Sales@BFTGateOpeners.com

selecting which motor is motor 1 and which is motor 2

motor 1 opens first and closes second; motor 2 opens second and closes first
only use 16 awg, stranded , sjtow or sjtoow cable.
avoid splices. if necessary , a splice must be above ground in a dry junction box

QUICK SETUP MENU

PRESS THE [OK] BUTTON ONCE TO ENTER. use [+] and [-] to find selection. use [ok] to select
l a n g
t yp e
(language)
ita (italian) eli
fra (french) phob (phobos)
deu (german) igea
eng (english)
esp (spanish)

preset table

features

AUTOMATIC CLOSING TIMER
PRE-ALARM
UNINTERRUPTED OPEN CYCLE
INSTANT REVERSE ON CLOSING
HOLD TO RUN
QUICK REMOTE PROGRAMMING

programming remotes

SIMULTANEOUSLY PRESS AND
HOLD THE 2 BUTTONS ON
YOUR REMOTE UNTIL THE
SCREEN READS "RELEASE"
█
75
phobos & igea BT wiring
motor thalia p
wire color
terminal motor 1 motor 2
1 white 42
2 red 10
3 black 11
*igea only – on left side operators, black &
red wires are swapped at the motor.
n ,mo t
dir
(number of p res et
(open direction)
motors)
2 int (interior) ar (automatic residential)
1 ext (exterior) sr (semi-automatic residential)
ac (automatic commercial)
sc (semi-automatic commercial)
ind (industrial)
A R S R A C S C
AUTOMATIC SEMI-AUTOMATIC AUTOMATIC SEMI-AUTOMATIC
RESIDENTIAL RESIDENTIAL COMMERCIAL COMMERCIAL
x x
x x
x x
x x
x x x x
– after you see "hidden button" displayed on the screen...
THE SCREEN WILL THEN READ
"DESIRED BUTTON". PRESS
THE BUTTON YOU WANT TO
OPERATE THE GATE WITH
thalia p
43
14
15
a u t o s et mem remo t es
hidden button
release
desired button
I N D
pre-alarm: aux with value set
to 6, active for 3 seconds
INDUSTRIAL
before gate movement
uninterrupted open cycle: a
start command will not stop
the gate from opening.
instant reverse: a start
command will stop and
reverse a closing gate.
x otherwise it just stops it and
an additional start command
will reverse it.
THE SCREEN WILL DISPLAY "OK"
AND THE NUMBER OF THE
REMOTE IN MEMORY . REPEAT THE
PROCESS FOR ADDITIONAL
REMOTES
