Vancouver II - 3 Door 3 Drawer Wardrobe
Assembly Instructions
Dimensions
Width - 1488cm
Depth - 603cm
Height -2057cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
- Please keep for future reference
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
643/8157
643/7866
643/7921
643/8243
Issue 1 - 06/10/09
