Summary of Contents for Argos Puerto Rico 641/7697
- Page 7 120mm 120mm...
-
Page 9: Puerto Rico
Puerto Rico - 1 Drawer Bedside Chest Assembly Instructions - Please keep for future reference 641/7697 643/1831 Dimensions Width - 53cm Depth - 48cm Height - 76cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 19/07/10... - Page 10 Safety and Care Advice Important Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the notice some variation in the grain pages 2 and 3.
- Page 11 Components - Panels Please check you have all the panels listed below 10 Drawer side x 2 (36 x 14cm) underside view from behind 1 Top panel (53 x 48cm) 11 Drawer back (34.4 x 14cm) 5 Front panel 12 Drawer runner x 2 (73.2 x 47.4cm) (37.6 x 4cm) 2 Right side panel...
- Page 12 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 13 Assembly Instructions Step 1 Fixing blocks to the right side panel. (Two people required for an easier assembly) Place blocks in the Yes! positions shown. Attention: The blocks must be aligned to the side edge. ttach blocks into right side panel using screws Repeat above procedures...
- Page 14 Assembly Instructions Step 3 Assembling the cabinet . Fit base panel to the side panels then fix using screws Step 4 Fixing panels. Two people required for an easier assembly. Fit side panels on the front panel Attach side panels on the front panel using screws Step 5...
- Page 15 Assembly Instructions Step 6 Fixing drawer runners. Fix side drawer runners to the side panels using screws shown. Step 7 Fix side plinths the side panels using screws Note: Make sure side plinths are aligned to the bottom and front edges of the side panels.
- Page 16 Assembly Instructions Step 9 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Holding the drawer back , press the drawer sides and fix them using screws Using screw attach...
- Page 17 Assembly Instructions Step 11 Hanging door. Attention: Door can be fitted left hand or right hand. Fix the hinges using screws as shown. Note: To ensure the alignment of the door is correct, centralise the door in the opening before attaching to the cabinet.
- Page 18 Assembly Instructions Step 13 Insert drawer into unit. With the back of the drawer past the front frame, use a hammer to tap dowels in flush to drawer sides. This is a safety catch to stop drawer falling out. Step 14 Fixing back panel.
- Page 19 Assembly Instructions Step 15 Fixing to wall. It is recommended that Note: Wall plugs not supplied. the furniture is fixed to a The correct type of fxing must wall. Fix wall strap be used for your wall, seek top of furniture using professional advice if in doubt.
-
Page 20: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
