Islington - Media Unit
Dimensions
Width - 90.5cm
Depth - 24cm
Height - 150.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
932/6950
932/6943
MADE IN
BRITAIN
Issue 1 - 31/03/11
Advertisement
Table of Contents
Related Manuals for Argos Islington
Summary of Contents for Argos Islington
- Page 1 Islington - Media Unit Assembly Instructions - 932/6950 Please keep for future reference 932/6943 Dimensions Width - 90.5cm Depth - 24cm MADE IN Height - 150.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 28kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D0827A) (903 x 169mm) Base (D0828A) (903 x 239mm) Middle Shelf (D0829A) (870 x 165mm) Left Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 2 top Finished uprights front edge Tap 2 short wooden 10mm dowels into each of the top uprights shown.
- Page 6 Assembly Instructions Step 4 Prepare the middle shelf Finished front edge Insert 4 large locking nuts into the middle shelf as shown. Note: The arrow on the locking nut must point towards the hole in the edge of the panel. Step 5 Finished front...
- Page 7 Assembly Instructions Step 7 Finished front Fit the other bottom edge upright 8mm holes Fit the other bottom upright to the assembly. Tap 4 long wooden 5.5mm holes dowels through the bottom upright into each of the shelves Step 8 Finished front Fit the bottom upright...
- Page 8 Assembly Instructions Step 10 Finished front edge Fit the shelves Push the shelves onto the top uprights Finished and bottom uprights front edge as shown. Note: Make sure that all of the shelves have the finished front edge pointing upwards. Step 11 Prepare the left side Screw 2 metal dowels...
- Page 9 Assembly Instructions Step 12 Fit the left side Push the left side onto the assembly. Finished Use a screwdriver to front edge tighten the 2 large locking nuts fitted to the middle shelf Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 10 Assembly Instructions Step 14 Finished Fit the right side front edge Push the right side onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to the middle shelf Step 15 Fit the base Finished Fit the base to the front edge assembly with 8 screws...
- Page 11 Assembly Instructions Step 17 Finished front edge Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted at the top of the left side and right side Turn the assembly Warning: The over for the next step.
- Page 12 Lift with care. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2592...
