Fora D40 DUO ultima Owner's Manual page 25

The FORA D40 is intended for use in the electromagnetic environment (for home healthcare and professional healthcare) specified below.
The customer or the user of the FORA D40 should assure that it is used in the environment specified below.
Immunity test
Conducted RF 3 Vrms:
IEC 61000-4-6 0,15 MHz – 80 MHz
6 Vrms:
in ISM and amateur
radio bands between
0,15 MHz and 80 MHz
80 % AM at 1 kHz
Radiated RF 10 V/m
IEC 61000-4-3 80 MHz – 2,7 GHz
80 % AM at 1 kHz
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply to all situations. Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur
radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the
location in which the FORA D40 is used exceeds the applicable RF compliance level above, the FORA D40 should be observed to verify
normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the
FORA D40.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
The FORA D40 is intended for use in an electromagnetic environment (for home healthcare and professional healthcare) in which radiated
RF disturbances are controlled. The customer or the user of the FORA D40 can help prevent electromagnetic interference by maintaining
a minimum distance between the portable and mobile RF communications equipment (transmitters) and the FORA D40 as recommended
below, depending on the maximum output power of the communications equipment.
Rated maximum output power
of transmitter
W
0,01
0,1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated
using the equation applicable to the frequency of the transmitter, where p is the maximum output power rating of the transmitter in watts (W)
depending on the transmitter manufacturer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE2 These guidelines may not apply to all situations. Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
Manufacturer's declaration-electromagnetic immunity
IEC 60601 test level Compliance level
Not applicable
Not applicable
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
Recommended separation distance between
portable and mobile RF communications equipment and the FORA D40
Separation distance according to frequency of transmitter
150 kHz to 80 MHz
d =1,2√P
N/A
N/A
N/A
N/A
N/A
Electromagnetic environment-guidance (for
home healthcare and professional healthcare
Portable and mobile RF communications equipment
must not be used close to any parts of the FORA
D40 including cables, other than the recommended
separation distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance:
d = 1,2 √P
d = 1,2 √P 80MHz to 800 MHz
d = 2,3 √P 800MHz to 2,7 GHz
Where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters, as determined
by an electromagnetic site survey,
the compliance level in each frequency range.
Interference may occur in the vicinity of equipment
marked with the following symbol:
m
80 MHz to 800 MHz
d =1,2√P
0,12
0,38
1,2
3,8
12
EN-23
environment)
a should be less than
b
800 MHz to 2,7 GHz
d =2,3√P
0,23
0,73
2,3
7,3
23
