ASSEMBLY INSTRUCTIONS
RiverRidge
Book Nook
®
Kids Cubby Storage Tower with Bookshelves
ITEM #: 02-161 White
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over.
Don't use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Book Nook 02-161 White and is the answer not in the manual?

Questions and answers

Related Manuals for RiverRidge Book Nook 02-161 White

Summary of Contents for RiverRidge Book Nook 02-161 White

  • Page 1 ASSEMBLY INSTRUCTIONS RiverRidge Book Nook ® Kids Cubby Storage Tower with Bookshelves ITEM #: 02-161 White ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children. During assembly children should be kept away from the product due to possible risk of injury.
  • Page 2 This product is suitable for children 3 years and older. THIS STORAGE TOWER WILL HOLD UP TO 20 POUNDS PER CUBBY AND HAS A TOP SHELF CAPACITY OF 30 POUNDS OR A TOTAL OF 90 POUNDS. DO NOT LOAD EACH CUBBY WITH MORE THAN 20 POUNDS. IF OVERLOADED WITH MORE THAN 20 POUNDS PER CUBBY OR 30 POUNDS ON THE TOP SHELF, THIS MAY CAUSE DAMAGE TO THE TOWER AND MAY CAUSE SERIOUS INJURY OR DEATH.

  • Page 3: Parts List

    PARTS LIST DESCRIPTION Top Board 2PCS Left & Right Support Panel 2PCS Left & Right Support Panel Bottom Board 2PCS Shelf 6PCS Cross Bar 6PCS Side Panel...
  • Page 4 PARTS LIST PARTS DESCRIPTION 16PCS Cam Bolt 16PCS Cam Lock 12PCS Wood Dowel Screw (4x10mm) Adjustable Anchor Bracket Plastic Anchor Screw (4x30mm) TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED) THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com.
  • Page 5 STEP 1 1. Screw 4 cam bolts (A) into cam bolt holes on top board (1). 2. Attach adjustable anchor bracket (E) to top board (1) by inserting 1 screw (D) through hole on adjustable anchor bracket (E,) then tighten to top board (1). STEP 2 ×2 ×2...
  • Page 6 STEP 4 1. Slide 4 side panels (7) into grooves on bottom board (4), shelves (5), left side panel (2) and right side panel (3). STEP 5 1. Insert 6 wood dowels (C) into wood dowel holes on another left support panel (2) and right support panel (3).
  • Page 7 STEP 6 1. Slide 2 side panels (7) into grooves on left support panels (2) and right support panels (3). STEP 7 1. Attach top board (1) to left support panels (2) and right support panels (3) by inserting cam bolts (A) into cam lock holes on left support panels (2) and right support panels (3).

  • Page 8: Care Instructions

    STEP 8 OPTION #1 OPTION #2 DRYWALL DRYWALL WOOD STUD SCREW WALL ANCHOR ONLY WITH SCREW Option #1: Securing to Drywall 1. Position storage tower and bracket (D) against wall in desired location. Using a pencil, make a small mark on wall through hole on bracket (D). Move tower away from wall and screw 1 plastic anchor (F) into wall on pencil mark.
  • Page 9 ® Thank you for purchasing this RiverRidge Home item. We hope you ® enjoy it and consider purchasing other RiverRidge items. ® To order replacement parts at no cost to you,email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
  • Page 10 ADULT ASSEMBLY REQUIRED Thank you for purchasing this RiverRidge Home item. We hope you ® enjoy it and consider purchasing other RiverRidge items. ® To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
