E10 Motor
Safety, Operation, Maintenance
& Parts Manual
LT15
LT15W
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
April 2010
rev. E2.00 - E8.13
rev. A1.00 - A1.14
Form #1100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer E10

  • Page 1 E10 Motor Safety, Operation, Maintenance & Parts Manual LT15 rev. E2.00 - E8.13 LT15W rev. A1.00 - A1.14 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine.
  • Page 2 Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...
  • Page 3: Table Of Contents

    Motor Starter Assembly .................4-1 LT15 Rev. E6.06+ Motor Starter Assembly .................4-3 LT15 Rev. E6.00 - E6.05 Motor Starter Assembly .................4-5 LT15 Rev. E2.00 - E5.00 Motor Assembly ..................4-7 Throttle/Clutch Assembly ..............4-8 LT15 E10 Rev. E1.00+ INDEX Table of Contents WMdoc072619...
  • Page 4: About This Manual

    SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment.
  • Page 5: Operation

    Operation Starting The Motor SECTION 2 OPERATION Starting The Motor DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. Turn the main switch on the starter box to the ON position.
  • Page 6: Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth- erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals.
  • Page 7 Maintenance Safety This symbol identifies the interval (hours of operation) at which each maintenance pro- cedure should be performed. "AR" signifies maintenance procedures which should be performed as required. Maintenance WMdoc072619...
  • Page 8: Replacement Parts

    Disconnect and lock out power supply before servicing! Keep all electrical component covers closed and securely fastened during machine operation. Failure to do so will result in severe personal injury. Wood-Mizer Products, Inc. 800-525-8100 Reorder #S20061 150178-1 E1001doc072619 Replacement Parts...
  • Page 9: Motor Starter Assembly

    017954 MOTOR MODULE, 10HP 3-PHASE 380-500V ELECTRIC MOTOR 017955 Motor Parts (See Section 4.4) Control Assembly, LT15 E10 3-Phase 240V 053713 Control Assembly, LT15 E10 3-Phase 460V 053738 Bolt, 5/16-18 x 3/4 Hex Head F05006-5 Bracket, Front Electric Motor Mount...
  • Page 10: Motor Starter Assembly

    STOP! Always wear eye, ear, respiration and foot protection when operating this machine. Failure to do so may result in injury. Wood-Mizer Products, Inc. 800-525-8100 Reorder #S11753 STOP! Read and understand operator’s manual and all safety instructions before setting up, operating or maintaining this machine.
  • Page 11 Replacement Parts Motor Starter Assembly NUT, 5/16-18 NYLON LOCK F05010-58 CONTROL ASSEMBLY, LT15 E10 3-PHASE 230V 052816 CONTROL ASSEMBLY, LT15 E10 3-PHASE 460V 052817 CONTROL ASSEMBLY, LT15 E10 3-PHASE 575V 052818 Electrical Components (See Component List) Bracket, Control Mount 038911 Bolt, 5/16-18 x 1”...
  • Page 12: Lt15 Rev. E2.00 - E5.00

    Replacement Parts Motor Starter Assembly Motor Starter Assembly LT15 Rev. E2.00 - E5.00 150112 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. STARTER ASSEMBLY, 10HP 3-PHASE 50/60HZ ELECTRIC MOTOR 088280-4 Bolt, M8 x 20-8.8 Hex Head F81002-4 Bracket, Electric Motor Starter Box, Electric Motor Starter Enclosure Timer, Y-Delta...
  • Page 13 Replacement Parts Motor Starter Assembly Contactor, LC1 D09 B7 084305 Contactor, LC1 D18 B7 084306 Switch, Modular 088278 Transformer, LT15 090562 Washer, 8.4mm Flat F81054-1 Nut, M8-8 Hex F81032-2 Switch, Electric Motor Starter Main 088265-1 Latch, Starter Box Door Bolt, M5 x 25 8.8 Socket Head F81000-7 Washer, 5.3mm Flat F81052-1...
  • Page 14: Motor Assembly

    BELT, BX85 DRIVE P25301 GUARD, MOTOR SHAFT LT15E 034904 SCREW, 3/8-16 X 1 HEX HEAD F05007-7 WASHER, 3/8 FLAT SAE F05011-3 NUT, 3/8-16 HEX NYLON LOCK F05010-10 DECAL, MOTOR DIRECTION S20097 DECAL, E10 ELECTRIC MOTOR WIRING 036058 E1001doc072619 Replacement Parts...
  • Page 15: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 E10 Rev. E1.00+ 150111G 16 17 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. KNOB, 5/8-11 BALL P04211 HANDLE, LT15 CLUTCH 016487 BUSHING, 5/8 ID X 7/8 OD X 1 1/8 LONG FL BRONZE...
  • Page 16 Replacement Parts Throttle/Clutch Assembly Bolt, 3/8-16 x 2 Hex Head Gr5 F05007-124 Nut, 3/8-16 Hex Nylon Lock F05010-10 Block, LT15 Brake 016488 Screw, 10-24 x 1 Socket Head F05004-2 Nut, #10-24 Keps F05010-14 Idler, 4" O.D. x 3/8 Bore 034602 Bolt, 3/8-16 x 2-3/4”...
  • Page 17: Index

    INDEX maintenance parts list motor assembly motor starter assembly 4-1, 4-3, 4-5 throttle/clutch starting Index E1001doc072619...
