SHB211 Series Quick Installation Guide
Description
Function
JP1
COM1
RS-232
(Default)
JP1
RS-422
JP1
RS-485
Description Jumper Setting
CF Device
Enable
(JP8~11)
(Default)
CF Device Voltage 3.3V
Selection (JP12) (Default)
LVDS Voltage
3.3V
Selection (JP18)
(Default)
USB Voltage
5V
Selection
(Default- JP17)
(JP14, JP15, JP17)
North Bridge Display Port
PCIEx16 Signal (Default-
Mode SHB211-
(JP20, JP21) PGGA )
Auto-Power Button Manual Power
Selection (JP13) Button (Default)
2
Jumper Setting
JP3
JP2
JP2 JP3
JP2 JP3
Disable
5V
5V
5V_SBY
(Default-
JP14, JP15)
PCIEx16
(Default-
SHB211-
VGGA )
Automatic
Power Button
©
Copyright 2009 AXIOMTEK Co., Ltd.
Version A1 March 2009
Printed in Taiwan
9418C211010E
SHB211 Series Quick Installation Guide
III.
Connectors
Connectors Label
CN1 SATA1 PORT
AUDIO CONNECTOR
CN2 SATA2 PORT
Front Panel CONNECTOR
FDD / PARALLEL CONNECTOR CN3
COMPACT FLASH
CN4 CONNECTOR
ATX POWER CONNECTOR
CN5 Ethernet1 PORT
CPU FAN CONNECTOR
CN6 Ethernet 2 PORT
SM BUS CONNECTOR
CN7 DDR3 SLOT1
SYSTEM FAN CONNECTOR
CN8 DDR3 SLOT2
SYSTEM FAN CONNECTOR
CN9 USB1 PORT
DISPLAY PORT(SHB211PGGA)
CN10 USB2 PORT
VGA PORT (SHB211VGGA)
CN11 USB3 / 4 CONNECTOR
LVDS CONNECTOR
CN12 USB5 / 6 CONNECTOR
LVDS Inverter CONNECTOR
COM1 KEYBORD CONNECTOR
COM1 PORT
COM2 MOUSE CONNECTOR
COM2 PORT
JP22 Thermal Sensor CONNECTOR
Thermal Sensor CONNECTOR
IV.
Front Panel Connectors
Power LED
Pins 1, 3, 5 connect the system power LED indicator to its corresponding switch
on the case. Pin 1 is +, and pin 5 assigned to -. Pin 3 is defined as NC.
External Speaker and Internal Buzzer Connector
Pins 2, 4, 6, 8 can be connected to the case-mounted speaker unit or internal
buzzer.
Power Button
Pins 9 and 10 connect the front panel's ATX power button to the card.
Hardware Reset
Pins 11 and 12 are designed for Hardware Reset.
HDD Activity LED
This connector extends to the hard drive activity LED on the control panel. This
©
