2. General explanation of the Excel Airide

Because there are several versions of Excel Airide available, in the following paragraphs all possible
embodiments are described.

2.1. Components of the Excel Airide B-ace version

16
15
14
13
12
11
10
1 Controller
2 Armpad
3 Clothing protector
4 Seat
5 Feet rest
6 Batteries
7 Feet plate
8 Anti-tip wheel
9 Drive wheel
10 Swivel wheel
11 Mudguard
12 Fork for the swivel wheel
13 Side frame
14 Back angle adjustment
15 Armrest
16 Backrest
17
18
1
2
3
4
5
6
7
8
9
